Features and options (continued)
Feature Unit Model
E100B E130B E147C
Shafts Splined 13-tooth, 14-tooth, 17-tooth
Straight Ø 38.08 mm [1.5 in]
Displacement limiters Optional, adjustable
Ratings
Rating Units Model
E100B E130B E147C
Input speed¹ minimum min-1 (rpm) 500 500 500
continuous 2450 2200 2100
maximum 2880 2600 2475
Working pressure continuous bar [psi] 310 [4495] 310 [4495] 260 [3770]
maximum 400 [5800] 400 [5800] 350 [5075]
External shaft loads External moment (Me) N•m [lbf•in] 455 [4030] 360 [3190] 396 [3500]
Thrust in (Tin), out (Tout) N [lbf] 2846 [640] 1735 [390] 2113 [475]
Thrust out (Tout) 7740 [1740] 6672 [1500] 7117 [1600]
Bearing life at 140 bar [2030 psi] B10 hours 77 200 32 700 21 600
at 210 bar [3045 psi] 19 800 8400 5500
at 260 bar [3770 psi] 9700 4116 2700
at 310 bar [4495 psi] 5400 2300 —
Mounting flange load
moments
Vibratory (continuous) N•m [lbf•in] 1920 [17 000]
Shock (max) 6779 [60 000]
(1) Input speeds are valid at 1 bar absolute [0 in Hg vac] inlet pressure. See Inlet pressure vs. speed charts
in the Series 45 Technical Information Manual 520L0519.
Service Manual
Series 45 E Frame Open Circuit Pumps
Technical specifications
