General specifications
Type of mounting
SAE-C mounting flange.
Auxiliary mounting pad options
SAE-A, SAE-B, SAE-B-B, SAE-C, SAE C-C
Control options
PC: Pressure Compensator
LS: Load Sensing (with PC)
Port options
Inlet and system ports:
•
SAE flanged ports, code 61 Inlet Code 62 outlet.
•
Axial (end) ports or radial (side) ports.
All other ports:
•
SAE straight thread O-ring boss.
Direction of rotation
Clockwise or counterclockwise.
Installation position
Installation position is discretionary. To satisfy inlet pressure conditions, it is recommended that the
pump always be located below the lowest level of hydraulic fluid in the reservoir. The housing must
always be filled with hydraulic fluid.
Technical specifications
Features and options
Feature Unit Model
E100B E130B E147C
Maximum Displacement cm³ [in³] 100 [6.10] 130 [7.93] 147 [8.97]
Flow at rated speed (theoretical) l/min
[US gal/min]
245
[64.7]
286
[75.6]
309
[81.6]
Input torque at maximum displacement (theoretical) N•m/bar
[lbf•in/1000 psi]
1.592
[972]
2.069
[1263]
2.340
[1428]
Mass moment of inertia of internal rotating
components
kg•m²
[slug•ft²]
0.0128
[0.0094]
0.0128
[0.0094]
0.0128
[0.0094]
Weight Axial ports kg [lb] 51.3 [113]
Radial ports 54.9 [121]
Rotation Clockwise, Counterclockwise
Mounting SAE-C
Auxiliary mounting SAE-A, SAE-B, SAE-BB, SAE-C, SAE-CC
System ports (type) 4-bolt split flange
System ports (location) Axial, Radial
Control types PC, Remote PC, LS, LS with internal bleed
Service Manual
Series 45 E Frame Open Circuit Pumps
Technical specifications
©
Danfoss | September 2016 AX00000024en-US0401 | 9
