Danfoss VLT 2010 User Manual

MG.20.B6.02 – VLT is a registered Danfoss trademark
VLT
®
2000 Series
74
✭ = Factory setting. Text in ( ) = Display text. The figures in [ ] are used in bus communication.
Description of parameters
405 Terminal 29 Jog (INPUT 29)
Value:
✭ Jog (JOG) [0]
Start (START) [1]
Digital reference (DIG.REF+START) [2]
Pulse input, 100 Hz (PULSES 100 Hz) [3]
Pulse input, 1 kHz (PULSES 1 kHz) [4]
Pulse input, 10 kHz (PULSES 10 kHz) [5]
Setup select (SETUP SELECT) [6]
Reset (RESET) [7]
Reversing (REVERSING) [8]
Speed down (SPEED DOWN) [9]
Function:
Using this parameter (terminal 29) you can give the
motor different signals.
Description:
You can set the output frequency to a pre-program-
med value (jog in parameter 203). Recording Digital
reference you can enable/disable values stored in
parameters 205-208.
If terminal 29 is used for either pulse signal reference
(open loop) or pulse signal feedback (closed loop),
choose one of the pulse inputs [3] - [5].
If Multi setup is selected in parameter 001, the termi-
nal can be used to switch between setups 1 and 2.
404 Terminal 27 stop (INPUT 27) (continued)
Value:
Motor coasting (MTR.COASTnot) [0]
Quick stop (Q-STOPnot) [1]
DC-brake (DC-BRAKEnot) [2]
✭ Reset and motor coasting (RESET&COASTnot) [3]
Stop (STOPnot) [4]
Reset and start (RESET&START) [5]
Speed up (SPEED UP) [6]
Digital reference select (SPEED SELECT) [7]
Speed up:
This is used together with parameter 230. It is
possible to make the output frequency increase
towards f
MAX
as long as 24 V is applied to terminal 18.
At 0 V on terminal 18 the output frequency in
question is maintained. See also parameter 403.
Digital reference select:
Together with parameter 402 you can choose
between four different digital references:
18/27 19 Terminal
0 0 Digital reference 1
1 0 Digital reference 2
0 1 Digital reference 3
1 1 Digital reference 4
■
■
