VLT® 5000 Crane
Name (index 6):
The Name returns a string value in ASCII format,
containing the name of the parameter.
Example:
In this example the master reads the name of
parameter 001, Language.
The following telegram must be sent to the
frequency converter:
STX LGE ADR PKE IND PWE
HIGH
PWE
LOW
PCD1 PCD2 BCC
02 0E 01 40 01 00 06 00 00 00 00 XX XX XX XX XX
STX = 02 Start byte
LGE = 0E Length of remaining telegram
ADR = Sends the frequency converter on
Address 1, Danfoss format
PKE = 4001; 4 in the PKE field indicates
a Read Parameter Description and
01 indicates parameter number
001, Language
IND = 0006; 6 indicates that Names is
required.
The response from the frequency converter will be:
STX LGE ADR PKE IND PVA PCD1 PCD2 BCC
02 12 01 30 01 00 06 4C41 4E47 5541
4745
XXXX XXXX XX
PKE = 3001; 3 are the response for Name
and 01 indicates the parameter
number 001, Language
IND = 00 06; 06 indicates that Name is
sent.
PVA = 4C 41 4E 47 55 41 47 45
LANGUAGE
The parameter value channel is now set up to a
visible string which returns an ASCII character for
each letter in the parameter name.
MG.50.N4.02 - VLT is a registered Danfoss trademark
108
