Danfoss VLT 5000 Crane Series - Mechanical Dimensions

VLT® 5000 Crane
Technical
Data
■ Mechanical Dimensions
■ Compact IP 00 and IP 20
IP 00 enclosure 400-500 V
VLT type A (mm) B (mm) C (mm) a (mm) b (mm) ab/be (mm) l/r (mm)
5152 - 5202 1400 420 400 1380 350 225 0
IP 20 enclosure 400-500 V
VLT type A (mm) B (mm) C (mm) a (mm) b (mm) ab/be (mm) l/r (mm)
5042 - 5062 800 308 296 780 270 200 0
5072 - 5102 800 370 335 780 330 225 0
ab: Min. space above enclosure.
be: Min. space below enclosure.
l/r: Min. distance between frequency converter and
other plant components, left and right sides.
VLT 5042-5102/400-500 V
VLT 5152-5202/400-500 V
