VLT® 5000 Crane
PNU Parameter Range Factory setting Changes Unit Conversion Data Protection
#
3xx
description
Inputs and outputs
during
operation
index index type level
300 Terminal 16, input Master/slave Yes 0 0 5 1
301 Terminal 17, input Positioning Yes 0 0 5 1
302 Terminal 18 Start,
input
Start lowering Yes 0 0 5 1
303 Terminal 19, input Start hoisting Yes 0 0 5 1
304 Terminal 27, input Crane Q stop inv. Yes 0 0 5 1
305 Terminal 29, input Gear choice Yes 0 0 5 1
306 Terminal 32, input Load contact 1 Yes 0 0 5 1
307 Terminal 33, input Load contact 2 Yes 0 0 5 1
308 Terminal 53,
analogue input
voltage
Reference Yes 0 0 5 1
309 Terminal 53, min.
scaling
0.0 - 10.0 V 0.0 V Yes 21 -1 5 1
310 Terminal 53, max.
scaling
0.0 - 10.0 V 10.0 V Yes 21 -1 5 1
314 Terminal 60,
analogue input
current
Reference Yes 0 0 5 1
315 Terminal 60, min.
scaling
0.0 - 20.0mA 4.0 mA Yes 22 -4 5 1
316 Terminal 60, max.
scaling
0.0 - 20.0mA 20.0 mA Yes 22 -4 5 1
317 Time out 0 sec 0 sec. Yes 4 0 5 1
318 Function after time
out
Off Yes 0 0 5 1
319 Terminal 42, output No operation Yes 0 0 5 1
321 Terminal 45, output No operation Yes 0 0 5 1
323 Relay 01, output Mechanical brake
control
Yes 0 0 5 1
324 Relay 01, ON delay 0.00 - 600
sec.
0.00 sec. Yes 4 -2 6 1
325 Relay 01, OFF delay 0.00 - 600
sec.
0.00 sec. Yes 4 -2 6 1
326 Relay 04, output Unit ready Yes 0 0 5 1
329 Encoder feedback
pulse/rev.
1024
pulses/rev.
1024 pulses/rev. No 0 0 6 1
341 Terminal 46, digital
signal output
No operation Yes 0 0 5 1
352 Terminal 58,
analogue input
current
Reference Yes 0 0 5 1
353 Terminal 58, min.
scaling
0.0 - 20.0 mA 4 mA Yes 22 -4 5 1
354 Terminal 50, max.
scaling
0.0 - 20.0 mA 20 mA Yes 22 -4 5 1
355 Terminal 26, digital
signal output
No operation Yes 0 0 5 1
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
MG.50.N4.02 - VLT is a registered Danfoss trademark
46
