VLT® 5000 Crane
Serial
communication
when each of the following is selected: Digital input
[0], Serial port [1], Logic and [2] or Logic or [3].
NB!:
Note that this parameter only is available when
the VLT 5000 Crane runs in FC profile.
Digital input [0]
Dig. input Ser. port Function
0 0 Stop
0 1 Stop
1 0 Start
1 1 Start
Serial port [1]
Dig. input Ser. port Function
0 0 Stop
0 1 Start
1 0 Stop
1 1 Start
Logic and [2]
Dig. input Ser. port Function
0 0 Stop
0 1 Stop
1 0 Stop
1 1 Start
Logic or [3]
Dig. input Ser. port Function
0 0 Stop
0 1 Start
1 0 Start
1 1 Start
506 REVERSING SELECT
Value:
✭Digital input (DIGITAL INPUT)
[0]
Serial port (SERIAL PORT)
[1]
Logic and (LOGIC AND)
[2]
Logic or (LOGIC OR)
[3]
Function:
See function description for parameter 503 Quick stop.
Description of choice:
The table below shows when the motor is running
clockwise and anti-clockwise when each of the
following is selected: Digital input [0], Serial port
[1], Logic and [2] or Logic or [3].
NB!:
Note that this parameter is only available when
the VLT 5000 Crane runs in FC profile.
Digital input [0]
Dig. input Ser. port Function
0 0 Clockwise
0 1 Clockwise
1 0 Anti-clockwise
1 1 Anti-clockwise
Serial port [1]
Dig. input Ser. port Function
0 0 Clockwise
0 1 Anti-clockwise
1 0 Clockwise
1 1 Anti-clockwise
Logic and [2]
Dig. input Ser. port Function
0 0 Clockwise
0 1 Clockwise
1 0 Clockwise
1 1 Anti-clockwise
Logic or [3]
Dig. input Ser. port Function
0 0 Clockwise
0 1 Anti-clockwise
1 0 Anti-clockwise
1 1 Anti-clockwise
512 DRIVE PROFILE
Value:
FC profile (FC PROTOCOL)
[1]
✭Crane Profile (CRANE PROTOCOL)
[3]
Function:
It is possible to choose between two different
control and functionality profiles.
Description of choice
:
Select the desired control word profile.
See Serial communication in Appendix for further
details of control word profiles.
NB!:
Note that changes to this parameter do not
take effect before after a power up.
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
