Danfoss VLT 5000 Instruction Manual

32
MG.60.N1.22 - VLT is a registered Danfoss trademark
VLT
®
5000 / VLT
®
6000 HVAC / VLT
®
8000 AQUA
Bit Value 0 1 Bit Value 0 1
00 32768 33 OFF 33 ON 00 32768
01 16384 32 OFF 32 ON 01 16384
02 8192 29 OFF 29 ON 02 8192
03 4096 27 OFF 27 ON 03 4096
04 2048 19 OFF 19 ON 04 2048
05 1024 18 OFF 18 ON 05 1024
06 512 17 OFF 17 ON 06 512
07 256 16 OFF 16 ON 07 256
08 128 no function 08 128
09 64 no function 09 64
10 32 no function 10 32
11 16 no function 11 16
12 8 no function 12 8 Remote Local
13 4 no function 13 4 Stopped Running
14 2 no function 14 2 No Warning Warning
15 1 no function 15 1 no Alarm Alarm
Bit Value 0 1 Bit Value 0 1
00 32768 Alarm Ctrl. Ready 00 32768 normal Brake Test fail
01 16384 Alarm Drive Ready 01 16384 normal Trip Lock
02 8192 Safety Open Safety Closed 02 8192 normal AMA Fault
03 4096 No Alarm Alarm 03 4096 normal AMA OK
04 2048 04 2048 normal Power Up Fault
05 1024 05 1024 normal ASIC Fault
06 512 06 512 normal HPFB Timeout
07 256 no Warning Warning 07 256 normal RS-485 Timeout
08 128 Not at Ref. at Ref. 08 128 normal Short circuit
09 64 Local Bus Control 09 64 normal Power Fault
10 32 Fr. Range Warn Freq. in Range 10 32 normal Ground Fault
11 16 Stopped Running 11 16 normal Over current
12 8 no used Stall, Autostart 12 8 normal Torque limit
13 4 normal Voltage Warn. 13 4 normal Motor Thermal
14 2 normal Current lim. 14 2 normal Motor Overload
15 1 normal Therm. Warning 15 1 normal Inverter Overload
Bit Value 0 1 Bit Value 0 1
00 32768 normal Brake Test Fault 00 32768 normal Ramping
01 16384 normal Ctrl. Crd. Fault 01 16384 normal AMT
02 8192 normal Pwr. Crd. Fault 02 8192 normal Start Fwd/Rev
03 4096 normal HPFB Timeout 03 4096 normal Slow down
04 2048 normal RS-485 Timeout 04 2048 normal Catch up
05 1024 normal Overcurrent 05 1024 normal FB High
06 512 normal Torque limit 06 512 normal FB Low
07 256 normal Thermistor O.T. 07 256 normal Current High
08 128 normal Motor O.T. 08 128 normal Current Low
09 64 normal Inverter O.T. 09 64 normal Freq. High
10 32 normal U.V. Alarm 10 32 normal Freg. Low
11 16 normal O.V. Alarm 11 16 normal Brake Test OK
12 8 normal U.V. Warning 12 8 normal Braking Max.
13 4 normal O.V. Warning 13 4 normal Braking
14 2 normal Input Phase Loss 14 2 normal Discharge OK
15 1 normal No motor 15 1 normal Out Freq. Range
not used
not used
not used
no function
no function
no function
no function
no function
no function
no function
no function
no function
no function
no function
no function
nvoDigitalInput
nvoDrvStatus
nvoStatusWord
nvoWarning1
nvoAlarmWord
nvoWarning2
VLT 5000 Drive
Status Bit
Definitions
