Danfoss VLT 5000 Instruction Manual

31
MG.60.N1.22 - VLT is a registered Danfoss trademark
VLT
®
5000 / VLT
®
6000 HVAC / VLT
®
8000 AQUA
Bit Value 0 1 Bit Value 0 1
00 32768 33 OFF 33 ON 00 32768
01 16384 32 OFF 32 ON 01 16384
02 8192 29 OFF 29 ON 02 8192
03 4096 27 OFF 27 ON 03 4096
04 2048 19 OFF 19 ON 04 2048
05 1024 18 OFF 18 ON 05 1024
06 512 17 OFF 17 ON 06 512
07 256 16 OFF 16 ON 07 256
08 128 no function 08 128
09 64 no function 09 64
10 32 no function 10 32
11 16 no function 11 16
12 8 no function 12 8
13 4 no function 13 4 Stopped Running
14 2 no function 14 2 No Warning Warning
15 1 no function 15 1 no Alarm Alarm
Bit Value 0 1 Bit Value 0 1
00 32768 Alarm Ctrl. Ready 00 32768 normal Unknown Fault
01 16384 Alarm Drive Ready 01 16384 normal Trip Lock
02 8192 Safety Open Safety Closed 02 8192 normal AMA Fault
03 4096 No Alarm Alarm 03 4096 normal HPFB Timeout
04 2048 04 2048 normal RS-485 Timeout
05 1024 05 1024 normal ASIC Fault
06 512 06 512 normal Short circuit
07 256 no Warning Warning 07 256 normal SMPS Fault
08 128 Not at Ref. at Ref. 08 128 normal Ground Fault
09 64 Hand Mode Auto Mode 09 64 normal Overcurrent
10 32 Fr. Range Warn Freq. in Range 10 32 normal Current limit
11 16 Stopped Running 11 16 normal Mtr. Thermistor
12 8 no used 12 8 normal Motor thermal
13 4 normal Voltage Warn. 13 4 normal Undervoltage
14 2 normal Current lim. 14 2 normal Overvoltage
15 1 normal Therm. Warning 15 1 normal In. Phase loss
Bit Value 0 1 Bit Value 0 1
00 32768 normal Ref. High 00 32768 normal Autoramping
01 16384 normal Ctrl. Crd. Fault 01 16384 normal Start Delay
02 8192 normal Pwr. Crd. Fault 02 8192 normal Sleep Boost
03 4096 normal HPFB Timeout 03 4096 normal Sleep
04 2048 normal RS-485 Timeout 04 2048 normal AMA Done
05 1024 normal Overcurrent 05 1024 normal AMA Running
06 512 normal Current limit 06 512 normal Rev. Start
07 256 normal Thermistor O.T. 07 256 no Ramp Ramping
08 128 normal Motor O.T. 08 128 Forward Reverse
09 64 normal Inverter O.T. 09 64 not at Ref. at Reference
10 32 normal U.V. Alarm 10 32 Stopped Running
11 16 normal O.V. Alarm 11 16 Remote Ref. Local Ref.
12 8 normal U.V. Warning 12 8 normal OFF (HOA)
13 4 normal O.V. Warning 13 4 Auto Start/stop Hand
14 2 normal Input Phase Loss 14 2 normal Run Request
15 1 normal Live Zero 15 1 Run Permission no Run Perm.
no function
not used
not used
not used
no function
no function
no function
no function
no function
no function
no function
no function
no function
no function
no function
no function
VLT 6000/8000
Drive Status Bit
Definitions
nvoWarning1 nvoWarning2
nvoStatusWord nvoAlarmWord
nvoDigitalInput
nvoDrvStatus
