Danfoss VLT 6000 series User Manual

VLT
®
6000 HVAC Series
PNU Parameter Factory setting Range Changes 4-Setup Conversion Data
# description during operation index type
300 Terminal 16, Digital input Reset Yes Yes 0 5
301 Terminal 17, Digital input Freeze output Yes Yes 0 5
302 Terminal 18, Digital input Start Yes Yes 0 5
303 Terminal 19, Digital input Reversing Yes Yes 0 5
304 Terminal 27, Digital input Coasting stop, inverse Yes Yes 0 5
305 Terminal 29, Digital input Jog Yes Yes 0 5
306 Terminal 32, Digital input No operation Yes Yes 0 5
307 Terminal 33, Digital input No operation Yes Yes 0 5
308 Terminal 53, analogue input voltage Reference Yes Yes 0 5
309 Terminal 53, min. scaling 0.0 V 0.0 - 10.0 V Yes Yes -1 5
310 Terminal 53, max. scaling 10.0 V 0.0 - 10.0 V Yes Yes -1 5
311 Terminal 54, analogue input voltage No operation Yes Yes 0 5
312 Terminal 54, min. scaling 0.0 V 0.0 - 10.0 V Yes Yes -1 5
313 Terminal 54, max. scaling 10.0 V 0.0 - 10.0 V Yes Yes -1 5
314 Terminal 60, analogue input current Reference Yes Yes 0 5
315 Terminal 60, min. scaling 4.0 mA 0.0 - 20.0 mA Yes Yes -4 5
316 Terminal 60, max. scaling 20.0 mA 0.0 - 20.0 mA Yes Yes -4 5
317 Time out 10 sec. 1 - 99 sec. Yes Yes 0 5
318 Function after time out Off Yes Yes 0 5
319 Terminal 42, output 0-I
MAX
0-20 mA Yes Yes 0 5
320 Terminal 42, output, pulse scaling 5000 Hz 1 - 32000 Hz Yes Yes 0 6
321 Terminal 45, output 0-f
MAX
0-20 mA Yes Yes 0 5
322 Terminal 45, output, pulse scaling 5000 Hz 1 - 32000 Hz Yes Yes 0 6
323 Relay 1, output function Alarm Yes Yes 0 5
324 Relay 01, ON delay 0.00 sec. 0 - 600 sec. Yes Yes 0 6
325 Relay 01, OFF delay 0.00 sec. 0 - 600 sec. Yes Yes 0 6
326 Relay 2, output function Running Yes Yes 0 5
327 Pulse reference, max. frequency 5000 Hz Depends on
input terminal
Yes Yes 0 6
328 Pulse feedback, max. frequency 25000 Hz 0 - 65000 Hz Yes Yes 0 6
364 Terminal 42, bus control 0 0.0 - 100 % Yes Yes -1 6
365 Terminal 45, bus control 0 0.0 - 100 % Yes Yes -1 6
Changes during operation:
"Yes" means that the parameter can be changed,
while the frequency converter is in operation. "No"
means that the frequency converter must be stopped
before a change can be made.
4
-Setup:
"Yes" means that the parameter can be programmed
individually in each of the four setups, i.e. the
same parameter can have four different data
values. "No" means that the data value will be
the same in all four setups.
C
onversion index:
This number refers to a conversion figure to
be used when writing or reading by means
of a frequency converter.
Conversion index Conversion factor
74 0.1
2 100
110
01
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
Data type:
Data type shows the type and length of the telegram.
Data type Description
3Integer16
4Integer32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9Textstring
MG.61.A5.02 - VLT is a registered Danfoss trademark
164
