Danfoss VLT 6000 series User Manual

VLT
®
6000 HVAC Series
■ Fuses
UL compliance
To comply with UL/cUL approvals, pre-fuses according to the table below must be used.
200-240 V
VLT Bussmann SIBA Littel fuse Ferraz-Shawmut
6002 KTN-R10 5017906-010 KLN-R10 ATM-R10 or A2K-10R
6003 KTN-R15 5017906-016 KLN-R15 ATM-R15 or A2K-15R
6004 KTN-R20 5017906-020 KLN-R20 ATM-R20 or A2K-20R
6005 KTN-R25 5017906-025 KLN-R25 ATM-R25 or A2K-25R
6006 KTN-R30 5017906-032 KLN-R30 ATM-R30 or A2K-30R
6008 KTN-R50 5012406-050 KLN-R50 A2K-50R
6011, 6016 KTN-R60 5014006-063 KLN-R60 A2K-60R
6022 KTN-R80 5014006-080 KLN-R80 A2K-80R
6027, 6032 KTN-R125 2028220-125 KLN-R125 A2K-125R
6042 FWX-150 2028220-150 L25S-150 A25X-150
6052 FWX-200 2028220-200 L25S-200 A25X-200
6062 FWX-250 2028220-250 L25S-250 A25X-250
380-460 V
Bussmann SIBA Littel fuse Ferraz-Shawmut
6002 KTS-R6 5017906-006 KLS-R6 ATM-R6 or A6K-6R
6003, 6004 KTS-R10 5017906-010 KLS-R10 ATM-R10 or A6K-10R
6005 KTS-R15 5017906-016 KLS-R16 ATM-R16 or A6K-16R
6006 KTS-R20 5017906-020 KLS-R20 ATM-R20 or A6K-20R
6008 KTS-R25 5017906-025 KLS-R25 ATM-R25 or A6K-25R
6011 KTS-R30 5012406-032 KLS-R30 ATM-R30 or A6K-30R
6016, 6022 KTS-R40 5014006-040 KLS-R40 A6K-40R
6027 KTS-R50 5014006-050 KLS-R50 A6K-50R
6032 KTS-R60 5014006-063 KLS-R60 A6K-60R
6042 KTS-R80 2028220-100 KLS-R80 A6K-80R
6052 KTS-R100 2028220-125 KLS-R100 A6K-100R
6062 KTS-R125 2028220-125 KLS-R125 A6K-125R
6072 KTS-R150 2028220-160 KLS-R150 A6K-150R
6102 FWH-220 2028220-200 L50S-225 A50-P225
6122 FWH-250 2028220-250 L50S-250 A50-P250
6152* FWH-300/170M30
17
2028220-315 L50S-300 A50-P300
6172* FWH-350/170M3018 2028220-315 L50S-350 A50-P350
6222* FWH-400/170M4012 206xx32-400 L50S-400 A50-P400
6272* FWH-500/170M4
014
206xx32-500 L50S-500 A50-P500
6352* FWH-600/170M4016 206xx32-600 L50S-600 A50-P600
6402 170M4017 2061032-700 6,9URD31D08A0700
6502 170M6013 2063032-900 6,9URD33D08A0
900
6552 170M6013 2063032-900 6,9URD33D08A0900
6602 170M6013 2063032-900 6,9URD33D08A0900
* Circuit Breakers manufactured by General Electric, Cat .No. SKHA36AT0800, with the rating plugs listed
below can be
used to meet UL requirement.
6152 rating plug N
o.
SRPK800 A 300
6172 rating plug No
.
SRPK800 A 400
6222 rating plug No. SRPK800 A 400
6272 rating plug No. SRPK800 A 500
6352 rating plug No. SRPK800 A 600
MG.61.A5.02 - VLT is a registered Danfoss trademark
38
