Programming
Digital input [0] Serial communication [1]
Serial Serial
Kl.19 com.Function
Kl.19 com.Function
0 0 Clockwise 0 0 Clockwise
0 1 Clockwise 0 1 Counter-
clock
1 0 Counter-
clock.
1 0 Clockwise
1 1 Counter-
clock.
1 1 Counter-
clock.
Logic and [2] Logic or [3]
Serial Serial
Kl.19 com.Function Kl.19 com.Function
0 0 Clockwise 0 0 Clockwise
0 1 Clockwise 0 1 Counter-
clock.
1 0 Clockwise 1 0 Counter-
clock.
1 1 Counter-
clock.
1 1 Counter-
clock.
507 Selection of Setup
(SELECTING OF SETUP)
508 Selection of preset reference
(SELECTING OF SPEED)
Value:
Digital input (DIGITAL INPUT)
[0]
Serial communication (SERIAL PORT)
[1]
Logic and (LOGIC AND)
[2]
✭Logic or (LOGIC OR)
[3]
Function:
See functional description under parameter
503 Coasting.
Description of choice:
The table below shows the Setup (parameter 002 Active
Setup) that has been selected via Digital input [0],Serial
communication [1], Logic and [2] or Logic or [3].
The table also shows the preset reference (parameters
211-214 Preset reference) that has been selected
via Digital input [0], Serial communication [1],
Logic and [2] or Logic or [3].
Digital input [0]
Bus
msb
Bus
lsb
Setup/Pre-
set
msb
Setup/Pre-
set
lsb
Setup no.
Preset ref.
no.
0 0 0 0 1
0
0 0 1 2
0
0 1 0 3
0
0 1 1 4
0 1 0 0 1
0
1 0 1 2
0
1 1 0 3
0
1 1 1 4
1 0 0 0 1
1
0 0 1 2
1
0 1 0 3
1
0 1 1 4
1 1 0 0 1
1
1 0 1 2
1
1 1 0 3
1
1 1 1 4
Serial communication [1]
Bus
msb
Bus
sb
Setup/Pre-
set
msb
Setup/Pre-
set
lsb
Setup no.
Preset ref.
no.
0 0 0 0 1
0
0 0 1 1
0
0 1 0 1
0
0 1 1 1
0 1 0 0 2
0
1 0 1 2
0
1 1 0 2
0
1 1 1 2
1 0 0 0 3
1
0 0 1 3
1
0 1 0 3
1
0 1 1 3
1 1 0 0 4
1
1 0 1 4
1
1 1 0 4
1
1 1 1 4
Logic and [2]
Bus
msb
Bus
lsb
Setup/Pre-
set
msb
Setup/Pre-
set
lsb
Setup no.
Preset ref.
no.
0 0 0 0 1
0
0 0 1 1
0
0 1 0 1
0
0 1 1 1
0 1 0 0 1
0
1 0 1 2
0
1 1 0 1
0
1 1 1 2
1 0 0 0 1
1
0 0 1 1
1
0 1 0 3
1
0 1 1 3
1 1 0 0 1
1
1 0 1 2
1
1 1 0 3
1
1 1 1 4
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
