VLT
®
8000 AQUA
Installation
■ Technical data, mains supply 3 x 200 - 240 V
According to international requirements VLT type 8016 8022 8027 8032 8042 8052 8062
Output current
4)
I
VLT,N
[A]
(200-230 V)
46.2 59.4 74.8 88.0 115 143 170
I
VLT, MAX
(60 s)
[A] (200-230 V)
50.6 65.3 82.3 96.8 127 158 187
I
VLT,N
[A] (240 V) 46.0 59.4 74.8 88.0 104 130 154
I
VLT, MAX
(60 s)
[A] (240 V)
50.6 65.3 82.3 96.8 115 143 170
Output power
S
VLT,N
[kVA]
(240 V)
19.1 24.7 31.1 36.6 41.0 52.0 61.0
Typical shaft
output
P
VLT,N
[kW] 11 15 18.5 22 30 37 45
Typical shaft
output
P
VLT,N
[HP] 15 20 25 30 40 50 60
Max. cable
cross-section
to motor and
DC-bus [mm
2
]/[AWG]
2) 5)
Copper
Aluminium
6)
16/6
16/6
35/2
35/2
35/2
35/2
50/0
50/0
70/1/0
95/3/0
5)
95/3/0
90/250
mcm
5)
120/4/0
120/300
mcm
5)
Min. cable cross-section to motor
and DC-bus [mm
2
]/[AWG]
2)
10/8 10/8 10/8 16/6 10/8 10/8 10/8
Max. input current (200 V) (RMS)
I
L,N
[A]
46.0 59.2 74.8 88.0 101.3 126.6 149.9
Max. cable
cross-section
power [mm
2
]/[AWG]
2) 5)
Copper
Aluminium
6)
16/6
16/6
35/2
35/2
35/2
35/2
50/0
50/0
70/1/0
95/3/0
5)
95/3/0
90/250
mcm
5)
120/4/0
120/300
mcm
5)
Max. pre-fuses [-]/UL
1)
[A] 60 80 125 125 150 200 250
Efficiency
3)
0.95 0.95 0.95 0.95 0.95 0.95 0.95
Weight IP
00/Chassis
[kg/lbs] - - - - 90/198 90/198 90/198
Weight IP
20/NEMA 1
[kg/lbs] 23/51 30/66 30/66 48/106 101/223 101/223 101/223
Weight IP 54 [kg/lbs] 38/84 49/108 50/110 55/121 104/229 104/229 104/229
Power loss at
max. load.
[W] 545 783 1042 1243 1089 1361 1613
Enclosure IP 00/IP 20/NEMA 1/IP 54/NEMA 12
1. Fortypeoffuse,seesectionFuses.
2. American Wire Gauge.
3. Measured using 30 m/100 ft screened motor cables at rated load and rated frequency.
4. Current ratings fulfill UL requirements for 208-240 V.
5. Connection stud 1 x M8 / 2 x M8.
6. Aluminium cables with cross section above 35 mm
2
must be connected by use of an Al-Cu connector.
MG.83.A2.02 - VLT is a registered Danfoss trademark
37
