130BF858.10
1
3
6
9
7
10
8
5
4
2
1 DC(+) bus rail 6 IGBT module
2 Screw (T20) 7 IGBT output busbar
3 IGBT output busbar 8 IGBT terminal screw (T40)
4 Snubber capacitor 9 IGBT screw (T25)
5 Nut (8 mm) 10 DC(-) bus rail
Illustration 11.13 IGBT Modules
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 215
11 11
