Option
Name
Description
[13]
24V Encoder 27/29
Single signal generated from 24 V High Threshold Logic (HTL) encoder connected to terminals
27 and 29. Configure the 24 V encoder interface in parameter group 5.7* 24 V Encoder Input. Pro-
gram terminals 27/29 to [0] No operation.
[14]
MCB 102 Absolute
The option is only available for VLT® Encoder Option MCB 102 with version 4.00 and newer and
when parameter 17-00 Encoders Connected is set to option [1] Two Encoders.
[15]
MCO Encoder 1 X56
[16]
MCO Encoder 2 X55
[20]*
Digital Potmeter
[21]
Analog Input X30/11
VLT® General Purpose I/O MCB 101
[22]
Analog Input X30/12
VLT® General Purpose I/O MCB 101
[29]
Analog Input X48/2
[37]
Analog Input X49/1
[38]
Analog Input X49/3
[39]
Analog Input X49/5
Parameter 3-17 Reference Resource 3
Table 201: Parameter 3-17 Reference Resource 3
3-17 Reference Resource 3
Default value: [11] Local bus reference
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select the reference input to be used for the 3
rd
reference signal. Parameter 3-15 Resource Reference 1, parameter 3-16 Resource Refer-
ence 2, and parameter 3-17 Resource Reference 3 define up to 3 different reference signals. The sum of these reference signals defines
the actual reference.
Option
Name
Description
[0]
No function
[1]
Analog Input 53
[2]
Analog Input 54
[3]
24V Encoder 32/33
[4]
MCB 102
[5]
MCB 103
[6]
Virtual Master
[7]
Frequency Input 29
N O T I C E
This option is only available in FC 302.
[8]
Frequency Input 33
AU275636650261en-000101 / 130R0334 | 133Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
