Danfoss VLT CANopen MCA 105 Programming Guide

•
•
Operating variable
Unit
Parameter 16-96 Maintenance Word
hex
Parameter 16-97 Alarm Word 3
hex
Parameter 16-98 Warning Word 3
hex
4.1.3.1 Status View I
This readout state is standard after start-up or initialization. Press [Info] to obtain information about the units linked to the shown
operating variables (1.1, 1.2, 1.3, 2 and 3). See the operating variables shown in the following illustration.
1.1
2
3
1.3
1.2
e30bp041.10
799 RPM
1 (1)
36.4 kW 7.83 A
0.000
53.2 %
S t a tus
Auto Remote Ramping
Illustration 10: Status View I
4.1.3.2 Status View II
See the operating variables (1.1, 1.2, 1.3, and 2) shown in the following illustration. In the example, speed, motor current, motor
power, and frequency are selected as variables in the 1
st
and 2
nd
lines.
1.1
2
1.3
1.2
e30bp062.10
207 RPM
1 (1)
24.4 kW 5.25 A
6.9 Hz
S
t a
tus
Auto Remote Running
Illustration 11: Status View II
4.1.3.3 Status View III
This state shows the event and action of the smart logic control.
e30bp063.10
778 RPM
1 (1)
4.0 kW 0.86 A
S t a tus
Auto Remote Running
State: 0 off 0 (off)
When: -
Do: -
Illustration 12: Status View III
4.1.4 Parameter Setup
The drive can be used for practically all assignments. The drive offers 2 programming modes:
Main menu mode
Quick menu mode
AU275636650261en-000101 / 130R033424 | Danfoss A/S © 2022.12
How to Program
VLT AutomationDrive FC 301/302
Programming Guide
