Set vir. mas.
pos. to actual
N O T I C E
This option is only available with software version 48.XX.
Signal for setting virtual master position = actual follower position. This is needed for setting the cor-
rect starting position for position-controlled virtual master ensuring that the virtual master position is
aligned with the physical position of the follower.
N O T I C E
This option is only available with software version 48.XX.
Sets the actual master position to the value of parameter 17-88 Master Home Position.
N O T I C E
This option is only available with software version 48.XX.
Changes the sign of the set target position. For example, if the set target is 1000, the activation of this
option changes the value to -1000.
N O T I C E
This option is only available with software version 48.XX.
Activates the master offset selected in parameter 3-26 Master Offset when parameter 17-93 Master Offset
Selection has a selection from [1] Absolute to [5] Relative Touch Sensor.
N O T I C E
This option is only available with software version 48.XX.
Enable signal for the virual master function. Only applicable when option [10] Synchronization is selec-
ted in parameter 1-00 Configuration Mode.
N O T I C E
This option is only available with software version 48.XX.
Starts the homing function selected in parameter 17-80 Homing Function. Must remain high until hom-
ing is done, otherwise homing is aborted.
N O T I C E
This option is only available with software version 48.XX.
Activates monitoring of the touch sensor input.
N O T I C E
This option is only available with software version 48.XX.
AU275636650261en-000101 / 130R0334 | 185Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
