Option
Function
[6]
Running/no warn-
ing
The output speed is higher than the speed set in parameter 1-81 Min Speed for Function at Stop
[RPM]. The motor runs and there are no warnings.
[7]
Run inrange/no
warn
The motor runs within the programmed current and speed ranges set in parameter 4-50 Warning
Current Low to parameter 4-53 Warning Speed High. There are no warnings.
[8]
Run on ref/no warn
The motor runs at reference speed. There are no warnings.
[9]
Alarm
An alarm activates the output. There are no warnings.
[10]
Alarm or warning
An alarm or warning activates the output.
[11]
At torque limit
The torque limit set in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Torque Limit Gen-
erator Mode has been exceeded.
[12]
Out of current
range
The motor current is outside the range set in parameter 4-18 Current Limit.
[13]
Below current, low
The motor current is lower than set in parameter 4-50 Warning Curent Low.
[14]
Above current, high
The motor current is higher than set in parameter 4-51 Warning Current High.
[15]
Out of speed range
The output frequency is outside the frequency range set in parameter 4-52 Warning Speed Low and
parameter 4-53 Warning Speed High.
[16]
Below speed, low
Output speed is lower than the setting in parameter 4-52 Warning Speed Low.
[17]
Above speed, high
The output speed is higher than the setting in parameter 4-53 Warning Speed High.
[18]
Out of feedb. range
Feedback is below the limit set in parameter 4-56 Warning Feedback Low and parameter 4-57 Warn-
ing Feedback High.
[19]
Below feedback,
low
Feedback is below the limit set in parameter 4-56 Warning Feedback Low.
[20]
Above feedback,
high
Feedback is above the limit set in parameter 4-57 Warning Feedback High.
[21]
Thermal warning
The thermal warning turns on when the temperature exceeds the limit in the motor, the drive, the
brake resistor, or the thermistor.
[22]
Ready, no thermal
W
The drive is ready for operation, and there is no overtemperature warning.
[23]
Remote, ready, no
TW
The drive is ready for operation and is in auto-on mode. There is no overtemperature warning.
[24]
Ready, voltage OK
The drive is ready for operation and the mains voltage is within the specified voltage range.
[25]
Reverse
The motor runs (or is ready to run) clockwise when logic = 0 and runs counterclockwise when logic
= 1. The output changes when the reversing signal is applied.
[26]
Bus OK
Active communication (no timeout) via the serial communication port.
[27]
Torque limit & stop
Used for coast stop and in torque limit conditions. If the drive has received a stop signal and is at
the torque limit, the signal is logic 0.
[28]
Brake, no brake war
Brake is active, and there are no warnings.
[29]
Brake ready, no
fault
Brake is ready for operation and there are no faults.
AU275636650261en-000101 / 130R0334 | 199Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
