Danfoss VLT CANopen MCA 105 Programming Guide

Operating variable
Unit
Parameter 16-11 Power [hp]
[hp]
Parameter 16-12 Motor Voltage
[V]
Parameter 16-13 Frequency
[Hz]
Parameter 16-14 Motor current
[A]
Parameter 16-15 Frequency [%]
%
Parameter 16-16 Torque [Nm]
Nm
Parameter 16-17 Speed [RPM]
[RPM]
Parameter 16-18 Motor Thermal
%
Parameter 16-20 Motor Angle
Parameter 16-21 Torque [%] High Res.
%
Parameter 16-22 Torque [%]
%
Parameter 16-23 Motor Shaft Power [kW]
kW
Parameter 16-24 Calibrated Stator Resistance
Ω
Parameter 16-25 Torque [Nm] High
Nm
Parameter 16-30 DC Link Voltage
V
Parameter 16-32 Brake Energy /s
kW
Parameter 16-33 Brake Energy Average
kW
Parameter 16-34 Heatsink Temp.
°C
Parameter 16-35 Inverter Thermal
%
Parameter 16-36 Inv. Nom. Current
A
Parameter 16-37 Inv. Max. Current
A
Parameter 16-38 SL Controller State (This is an array parameter with the selections 16-38.0–16-38.3).
Parameter 16-39 Control Card Temp.
°C
Parameter 16-40 Logging Buffer Full
Parameter 16-42 Service Log Counter
Parameter 16-43 Timed Actions Status
Parameter 16-45 Motor Phase U Current
A
Parameter 16-46 Motor Phase V Current
A
Parameter 16-47 Motor Phase W Current
A
Parameter 16-48 Speed Ref. After Ramp [RPM]
RPM
Parameter 16-49 Current Fault Source
Parameter 16-50 External Reference
