Danfoss VLT CANopen MCA 105 Programming Guide

•
•
•
Option
Name
Description
[1605]
Main Actual Value [%]
View the 2-byte word sent with the status word to the bus master reporting the
main actual value in %.
[1606]
Actual Position
Actual position in position units selected in parameter 17-70 Position Unit.
[1607]
Target Position
Active target position in position units selected in parameter 17-70 Position Unit.
[1608]
Position Error
Actual position PI error in position units selected in parameter 17-70 Position Unit.
[1609]
Custom Readout
View the user-defined readouts as defined in:
Parameter 0-30 Custom Readout Unit
Parameter 0-31 Custom Readout Min Value
Parameter 0-32 Custom Readout Max Value
[1610]
Power [kW]
Actual power consumed by the motor in kW.
[1611]
Power [hp]
Actual power consumed by the motor in hp.
[1612]
Motor Voltage
Voltage supplied to the motor.
[1613]
Frequency
Motor frequency, that is, the output frequency from the drive in Hz.
[1614]
Motor Current
Phase curent of the motor measured as effective value.
[1615]
Frequency [%]
Motor frequency, that is, the output frequency from the drive in percent.
[1616]
Torque [Nm]
Actual motor torque in Nm.
[1617]*
Speed [RPM]
Speed in RPM (revolutions per minute), that is, the motor shaft speed in closed loop.
[1618]
Motor Thermal
Thermal load on the motor calculated by the ETR function.
[1619]
Thermistor Sensor Temperature
[1620]
Motor Angle
[1621]
Torque [%] High Res.
[1622]
Torque [%]
Present motor load as a percentage of the rated motor torque.
[1623]
Motor Shaft Power [kW]
[1624]
Calibrated Stator Resistance
[1625]
Torque [Nm] High
[1628]
Angle Error
[1630]
DC Link Voltage
DC-link voltage in the drive.
[1631]
System Temp.
[1632]
Brake Energy /s
Present brake power transferred to an external brake resistor. Stated as an instant
value.
[1633]
Brake Energy Average
Brake power transferred to an external brake resistor. The mean power is calculated
continuously for the most recent 120 s.
[1634]
Heatsink Temp.
Present heat sink temperature of the drive. The cutout limit is 95 ±5 °C (203 ±9 °F);
cutting back in occurs at 70 ±5 °C (158 ±9 °F).
[1635]
Inverter Thermal
Percentage load of the inverters.
