Danfoss VLT CANopen MCA 105 Programming Guide

Option
Name
Description
[15]
Select preset ref 5
Selects preset reference 5. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
[16]
Select preset ref 6
Selects preset reference 6. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
[17]
Select preset ref 7
Selects preset reference 7. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
[18]
Select ramp 1
Selects ramp 1.
[19]
Select ramp 2
Selects ramp 2.
[20]
Select ramp 3
Selects ramp 3.
[21]
Select ramp 4
Selects ramp 4.
[22]
Run
Issues a start command to the drive.
[23]
Run reverse
Issues a start reverse command to the drive.
[24]
Stop
Issues a stop command to the drive.
[25]
Qstop
Issues a quick stop command to the drive.
[26]
Dcstop
Issues a DC stop command to the drive.
[27]
Coast
The drive coasts immediately. All stop commands including the coast command stop the SLC.
[28]
Freeze output
Freezes the output frequency of the drive.
[29]
Start timer 0
Starts timer 0, see parameter 13-20 SL Controller Timer for further description.
[30]
Start timer 1
Starts timer 1, see parameter 13-20 SL Controller Timer for further description.
[31]
Start timer 2
Starts timer 2, see parameter 13-20 SL Controller Timer for further description.
[32]
Set digital out A low
Any output with smart logic output A is low.
[33]
Set digital out B low
Any output with smart logic output B is low.
[34]
Set digital out C low
Any output with smart logic output C is low.
[35]
Set digital out D low
Any output with smart logic output D is low.
[36]
Set digital out E low
Any output with smart logic output E is low.
[37]
Set digital out F low
Any output with smart logic output F is low.
[38]
Set digital out A high
Any output with smart logic output A is high.
[39]
Set digital out B high
Any output with smart logic output B is high.
[40]
Set digital out C high
Any output with smart logic output C is high.
[41]
Set digital out D high
Any output with smart logic output D is high.
[42]
Set digital out E high
Any output with smart logic output E is high.
[43]
Set digital out F high
Any output with smart logic output F is high.
[60]
Reset Counter A
Resets counter A to 0.
[61]
Reset Counter B
Resets counter B to 0.
AU275636650261en-000101 / 130R0334 | 443Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
