Danfoss VLT CANopen MCA 105 Programming Guide

Option
Name
Description
[1675]
Analog In X30/11
Actual value at input X30/11 either as reference or protection value.
[1676]
Analog In X30/12
Actual value at input X30/12 either as reference or protection value.
[1677]
Analog Out X30/8 [mA]
Actual value at output X30/8 in mA. Use parameter 6-60 Terminal X30/8 Output to se-
lect the value to be shown.
[1678]
Analog Out X45/1 [mA]
[1679]
Analog Out X45/3 [mA]
[1680]
Fieldbus CTW 1
Control word (CTW) received from the bus master.
[1681]
Fieldbus Sync. REF
[1682]
Fieldbus REF 1
Mains reference value sent with control word from the bus master.
[1683]
Fielbus Pos. REF
[1684]
Comm. Option STW
Extended fieldbus communication option status word.
[1685]
FC Port CTW 1
Control word (CTW) received from the bus master.
[1686]
FC Port REF 1
Status word (STW) sent to the bus master.
[1687]
Bus Readout Alarm/Warning
[1688]
Fieldbus Torque FF
[1689]
Configurable Alarm/Warning
Word
[1690]
Alarm Word
One or more alarms in a hex code.
[1691]
Alarm Word 2
One or more alarms in a hex code.
[1692]
Warning Word
One or more warnings in a hex code.
[1693]
Warning Word 2
One or more warnings in a hex code.
[1694]
Ext. Status Word
One or more status conditions in a hex code.
[1695]
Ext. Status Word 2
One or more status conditions in a hex code.
[1696]
Maintenance Word
The bits reflect the status for the programmed preventice maintenance events in
parameter group 23-1* Maintenance.
[1697]
Alarm Word 3
[1698]
Warning Word 3
[1804]
Mech Brake Count
[1820]
Commanded Position
[1821]
Master Position
[1823]
Virtual Master Pos.
[1827]
Safe Opt. Est. Speed
[1828]
Safe Opt. Meas. Speed
[1829]
Safe Opt. Speed Error
AU275636650261en-000101 / 130R0334 | 45Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
