Option
Name
Description
[0]*
Trip Lock
A trip lock is triggered upon a mains phase imbalance.
[1]
Warning
A warning is issued upon a mains phase imbalance.
[2]
Disabled
Mains failure detection is disabled.
[3]
Derate
The drive derates upon a mains phase imbalance.
[4]
Trip
The drive trips.
[5]
Fast Trip Lock
A trip lock occurs when a mains input phase is missing.
[6]
Fast Trip
The drive trips when a mains input phase is missing.
[7]
Fast Warning
A warning occurs when a mains input phase is missing.
Parameter 14-14 Kin. Back-up Time-up
Table 711: Parameter 14-14 Kin. Back-up Time-up
14-14 Kin. Back-up Time-up
Default value: 60 s
Parameter type: Range, 0 - 60 s
Setup: All setups
Conversion index: 0
Data type: Uint8
Change during operation: True
This parameter defines the kinetic back-up timeout in flux mode when running on low voltage grids. If the supply voltage does not
exceed the value defined in parameter 14-11 Mains Fault Voltage Level +5% within the specified time, the drive automatically runs a
controlled ramp-down profile before stop.
Parameter 14-15 Kin. Back-up Trip Recovery Level
Table 712: Parameter 14-15 Kin. Back-up Trip Recovery Level
14-15 Kin. Back-up Trip Recovery Level
Default value: Size related
Parameter type: Range, 0 - 60000.000 Reference- FeedbackUnit
Setup: All setups
Conversion index: -3
Data type: Uint32
Change during operation: True
This parameter specifies the kinetic back-up trip recovery level. The unit is defined in parameter 0-02 Motor Speed Unit.
Parameter 14-16 Kin. Back-up Gain
Table 713: Parameter 14-16 Kin. Back-up Gain
14-16 Kin. Back-up Gain
Default value: 100%
Parameter type: Range, 0 - 500%
Setup: All setups
Conversion index: 0
Data type: Uint32
Change during operation: True
Enter the kinetic back-up gain value in percent.
Parameter 14-17 Fast Mains Phase Loss Level
Table 714: Parameter 14-17 Fast Mains Phase Loss Level
14-17 Fast Mains Phase Loss Level
Default value: 100
Parameter type: Range, 0 - 500
Setup: All setups
Conversion index: -3
Data type: Uint32
Change during operation: True
Set the level at which the functions Fast Mains Phase Loss Trip or Fast Mains Phase Loss Warning (see parameter 14-12 Response to
Mains Imbalance) should be activated.
