Parameter 32-38 Absolute Encoder Cable Length
Table 1134: Parameter 32-38 Absolute Encoder Cable Length
32-38 Absolute Encoder Cable Length
Default Value: 0
Parameter Type: Range, 0 - 300 m
Setup: 2 setups
Conversion Index: 0
Data Type: Uint16
Change during operation: True
Set the total cable length (in meters) to avoid that the absolute encoder (SSI) signals come out of synchronization due to signal
delays caused by long encoder cables. VLT® Motion Control Option MCO 305 and VLT® Motion Control Option MCO 302 compen-
sate for the cable delay when the cable length is known.
Parameter 32-39 Encoder Monitoring
Table 1135: Parameter 32-39 Encoder Monitoring
32-39 Encoder Monitoring
Default value: [0] Off
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
Off
[1]
3 channels
[2]
2 channels
[3]
Warning
[4]
Alarm
Parameter 32-40 Encoder Termination
Table 1136: Parameter 32-40 Encoder Termination
32-40 Encoder Termination
Default value: [1] No action
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[1]*
No action
[2]
Reference reversed
[3]
User units reserved
[4]
Uu and ref reversed
Parameter 32-43 Enc.1 Control
Table 1137: Parameter 32-43 Enc.1 Control
32-43 Enc.1 Control
Default value: [0] No soft changing
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
AU275636650261en-000101 / 130R0334594 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
