Option
Name
Description
[0]*
Inactive
[1]
Active
Parameter 33-44 Positive Software End Limit Active
Table 1201: Parameter 33-44 Positive Software End Limit Active
33-44 Positive Software End Limit Active
Default value: [0] Inactive
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
When this parameter is set to active, the drive continuously checks whether the target position is above the positive software limit.
If the position is outside the limit, an error is issued and the drive control is switched off.
Option
Name
Description
[0]*
Inactive
[1]
Active
Parameter 33-45 Time in Target Window
Table 1202: Parameter 33-45 Time in Target Window
33-45 Time in Target Window
Default value: 0
Parameter type: Range, 0 - 10 ms
Setup: 2 setups
Conversion index: -3
Data type: Uint8
Change during operation: True
Parameter 33-46 Target Window LimitValue
Table 1203: Parameter 33-46 Target Window LimitValue
33-46 Target Window LimitValue
Default value: 1
Parameter type: Range, 1 - 10000 ms
Setup: 2 setups
Conversion index: 0
Data type: Uint16
Change during operation: True
Parameter 33-47 Size of Target Window
Table 1204: Parameter 33-47 Size of Target Window
33-47 Size of Target Window
Default value: 0
Parameter type: Range, 0 - 10000 ms
Setup: 2 setups
Conversion index: 0
Data type: Uint16
Change during operation: True
Defines the size of the target window with user unit. A position is only viewed as reached when the actual position is within this
window.
AU275636650261en-000101 / 130R0334608 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
