Danfoss VLT CANopen MCA 105 Programming Guide

Option
Name
Description
[0]*
Controlled stop
[1]
Contr. stop + outp=0
[2]
Contr. stop + outp=1
Parameter 33-85 MCO Supplied by External 24VDC
Table 1231: Parameter 33-85 MCO Supplied by External 24VDC
33-85 MCO Supplied by External 24VDC
Default value: [0] No
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
No
[1]
Yes
Parameter 33-86 Terminal at Alarm
Table 1232: Parameter 33-86 Terminal at Alarm
33-86 Terminal at Alarm
Default value: [0] Relay 1
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
Relay 1
[1]
Relay 2
[2]
Terminal 27 digital output
[3]
Terminal 29 digital output
Parameter 33-87 Terminal State at Alarm
Table 1233: Parameter 33-87 Terminal State at Alarm
33-87 Terminal State at Alarm
Default value: [0] Do nothing
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
Do nothing
[1]
High
[2]
Low
AU275636650261en-000101 / 130R0334622 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
