FC 300 Design Guide
How to Program
Function:
Enables selection of control sourc e in Instance
21/71 and 20-70.
- Off: Enables control via analog/digital inputs.
- On: Enables control via the bus.
" 10-2* COS Filters
10-20 COS F ilter 1
Range:
0 - 65535
*
65535
Function:
Sets up the filter mask for the status word.
When operating in COS (Change-Of-State),
you c an filter out bits in the status word that
should not be sent if they change.
10-21 COS F ilter 2
Range:
0 - 65535
*
65535
Function:
Sets up the filter mask for the Main Actual Value.
When operating in COS (Change-Of-State), you
can filter out bits in the Ma in actual value that
should not be sent if they change.
10-22 COS F ilter 3
Range:
0 - 65535
*
65535
Function:
Sets up the filter mask for P CD 3. W h en operating
in COS (Change-Of-State), you can filter out bits in
PCD 3 that should not be sent if they change.
10-23 COS F ilter 4
Range:
0 - 65535
*
65535
Function:
Sets up the filter mask for P CD 4. W h en operating
in COS (Change-Of-State), you can filter out bits in
PCD 4 that should not be sent if they change.
" 10-3* Parameter Access
10-30 Array Index
Range:
0 - 65536
*
0
Function:
This parameter is used for accessing
indexed parameters.
10-31 Sto re Data Values
Option:
*
Off [0]
Store edit setup [1]
Store all set up s [2]
Function:
Par. 10-31 is used to activate storing of data
in non-volatile memory.
10-32 Devicenet Revision
Range:
0-65535N/A
*
0N/A
Function:
Par. 10-32 is used for EDS file creation.
10-33 Store Always
Option:
*
Off [0]
On [1]
Function:
This parameter selects if data parameters received
on DeviceNet should be stored in EEPROM as default.
10-39 Devicenet F Parameters
Array [1000]
Option:
No LCP acce ss
0-0
*
0
Function:
This parameter is used to configure the drive
via Devi
cenet a nd build the EDS file.
*
default setting ()display text []value for use in communication via serial communication port
194
MG.33.B
3.22 - VLT is a registered Danfoss trademark
