FC 300 Design Guide
How to Program
16-33 Brake Energy /2 min
Range:
0.000 - 0.000 kW
*
0.000kW
Function:
Returns the brake power transmitted to an external
brake resistor. The mean power is calcula ted on
an average basis for the latest 120 s.
16-34 Heatsin k Temp.
Range:
0-0°C
*
0°C
Function:
States the drive heat sink temperature. The cut-out
limit is 90 ± 5 °C (194 ± 9 °F), while the unit
cuts back in at 60 ± 5 °C (140 ± 9 °F).
16-35 Inverter T hermal
Range:
0-0%
*
0%
Function:
Returns the percentage load of the inverters.
16-36 Inv. Nom. C urrent
Range:
0.01 - 100.00 A
*
A
Function:
The value should equal the nameplate data
on the connected motor. The d ata is used for
calculation of torq u e, motor protection etc.
Changing the value in this p arameter affects
the setting of other parameters.
16-37 Inv. Max. Current
Range:
0.01 - 100.00 A
*
A
Function:
The value should equal the nameplate data
on the connected motor. The d ata is used for
calculation of torq u e, motor protection etc.
Changing the value in this p arameter affects
the setting of other parameters.
16-38 SL Controller State
Range:
0-0
*
0
Function:
Returns the state of which event the controller
is going to execute.
16-39 Control Card Temp.
Range:
0-0°C
*
0°C
Function:
Returns the temperature on the control
card i n degree °C.
16-40 Logging Buffer Full
Option:
*
No [0]
Yes [1]
Function:
Returns if the Data Log is full (see par. 15-1).
The log will never fill when Logging Mode (see
par. 15-13) is set to Log always.
" 16-5* Ref. & Feedb.
16-50 External Reference
Range:
0.0 - 0.0
*
0.0
Function:
Returns the total reference sum of digital/ana-
log/preset/bus/freeze ref./catch up and slow-down.
16-51 Pulse Reference
Range:
0.0 - 0.0
*
0.0
Function:
Returns the reference value from programmed
digital input(s). The readout can also be the
impulses from an incremental encoder.
16-52 Feedback [Unit]
Range:
0.0 - 0.0
*
0.0
Function:
Gives the resulting feedback value by m eans
of the unit/scaling selected in par. 3-00,
3-01, 3-02 and 3-03.
*
default setting ()display text []value for use in communication via serial communication port
216
MG.33.B
3.22 - VLT is a registered Danfoss trademark
