Parameter Option Default Function
Parameter 0-06 GridType [100] 200–240 V/60 Hz/IT-grid
[101] 200–240 V/60 Hz/Delta
[102] 200–240 V/60 Hz
[110] 380–440 V/60 Hz/IT-grid
[111] 380–440 V/60 Hz/Delta
[112] 380–440 V/60 Hz
[120] 440–480 V/60 Hz/IT-grid
[121] 440–480 V/60 Hz/Delta
[122] 440–480 V/60 Hz
[130] 525–600 V/60 Hz/IT-grid
[131] 525–600 V/60 Hz/Delta
[132] 525–600 V/60 Hz
Size related Select the operating mode for restart after
reconnection of the drive to mains voltage
after power-down.
Parameter 0-60 Main Menu
Password
0–99 0 Define the password for access to the LCP.
Parameter 1-00 Configuration
Mode
[0] Open loop
[3] Closed loop
[0] Open loop Select closed loop.
Parameter 1-13 Compressor Se-
lection
[24] VZH028-R410A
[25] VZH035-R410A
[26] VZH044-R410A
[27] VLZ028
[28] VLZ035
[29] VLZ044
Size related Select the compressor used.
Parameter 3-02 Minimum Ref-
erence
0–200 Hz 30 Hz The minimum reference is the lowest value
obtainable by summing all references.
Parameter 3-03 Maximum Ref-
erence
0–200 Hz 200 Hz The maximum reference is the highest ob-
tainable by summing all references.
Parameter 3-10 Preset Refer-
ence
-100 to +100% 0% Set up a fix setpoint in preset reference [0].
Programming
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 33
Danfoss A/S © 2019.12
