Drive 4 TR/VZH028 5 TR/VZH035 6.5 TR/
VZH044
13 TR/
VZH088
17 TR/
VZH117
26 TR/
VZH170
Intermittent (3x441–480
V) [A]
– – 17 37.4 44 57.2
Output current - 50 °C (122 °F) ambient temperature
Continuous (3x380–440
V) [A]
34.1 38 48.8
Intermittent (3x380–440
V) [A]
37.5 41.8 53.7
Continuous (3x441–480
V) [A]
31.3 35 41.6
Intermittent (3x441–480
V) [A]
34.4 38.5 45.8
Maximum input current
Continuous (3x380–440
V) [A]
12.7 15.1 18 35.2 42.6 57
Intermittent (3x380–440
V) [A]
– – 19.8 38.7 45.7 62.7
Continuous (3x441–480
V) [A]
10.8 12.6 17 29.3 34.6 49.2
Intermittent (3x441–480
V) [A]
– – 18.7 32.2 38.1 54.1
Maximum mains fuses see 3.2.4.5 Recommendation of Fuses.
Estimated power loss
[W], best case/typical
(1)
104/131 159/198 248/274 412/456 475/523 733
Weight enclosure pro-
tection rating IP20 [kg
(lb)]
4.3 (9.5) 4.3 (9.5) 7.9 (17.4) 9.5 (20.9) 9.5 (20.9) 24.5 (54)
Efficiency [%], best case/
typical
(2)
98.4/98 98.2/97.8 98.1/97.9 98.1/97.9 98.1/97.9 97.8
1
Applies for dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses may increase. LCP and typical control card power consump-
tions are included. For power loss data according to EN 50598-2, refer to the section on energy efficiency at www.danfoss.com.
2
Efficiency measured at nominal current. For energy efficiency class, see 6.5.14 Ambient Conditions. For part load losses, see the section on energy efficiency at www.dan-
foss.com.
6.3 EMC Emission Test Results
The following test results have been obtained using a system with a drive, a shielded control cable, a control box with potentiometer,
and a shielded motor cable.
Specifications
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
44 | Danfoss A/S © 2019.12
