Page #19 background imageLoading...
Page #19 background image
3.2.4.4 UL/Non-UL Compliance
To ensure compliance with UL or IEC 61800-5-1, use the circuit breakers or fuses listed in this chapter. Circuit breakers must be
designed for protection in a circuit capable of supplying a maximum of 10000 A
rms
(symmetrical), 480 V maximum.
3.2.4.5 Recommendation of Fuses
NOTICE
If malfunction occurs, failure to follow the protection recommendation may result in damage to the drive.
Table 11: Fuses
Fuse
UL Non-UL
Bussmann Bussmann Bussmann Bussmann Maximum fuse
Power [kW (hp)] Type RK5 Type RK1 Type J Type T Type G
3x200–240 V IP20
6.0 (8.0) FRS-R-50 KTN-R50 JKS-50 JJN-50 50
7.5 (10) FRS-R-50 KTN-R50 JKS-50 JJN-50 50
10 (15) FRS-R-80 KTN-R80 JKS-80 JJN-80 65
3x380–480 V IP20
6.0 (8.0) FRS-R-25 KTS-R25 JKS-25 JJS-25 25
7.5 (10) FRS-R-25 KTS-R25 JKS-25 JJS-25 25
10 (15) FRS-R-50 KTS-R50 JKS-50 JJS-50 50
18.5 (25) FRS-R-80 KTS-R80 JKS-80 JJS-80 63
22 (30) FRS-R-80 KTS-R80 JKS-80 JJS-80 63
30 (40) FRS-R-125 KTS-R125 JKS-R125 JJS-R125 80
3.2.5 EMC-correct Electrical Installation
General points to be observed to ensure EMC-correct electrical installation:
Use only shielded/armored motor cables and shielded/armored control cables.
Ground the shield at both ends.
Avoid installation with twisted shield ends (pigtails), because it reduces the shielding effect at high frequencies. Use the cable
clamps provided.
Ensure the same potential between the drive and the ground potential of PLC.
Use star washers and galvanically conductive installation plates.
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 19
Danfoss A/S © 2019.12
