Page #20 background imageLoading...
Page #20 background image
B
a
c
k
OK
Com.
On
Warn.
Alarm
Hand
On
Reset
Auto
On
Menu
Status Quick
Menu
Main
Menu
L1
L2
L3
PE
Minimum 16 mm
2
equalizing cable
Control cables
All cable entries in
one side of panel
Grounding rail
Cable insula-
tion stripped
Output con-
tactor
Motor cable
Motor, 3 phases and
PLC
Panel
Mains-supply
Minimum 200 mm (7.87 in)
between control
cable, mains cable
and between mains
motor cable
PLC
protective earth
Reinforced protective earth
e30bb761.12
(6 AWG)
Illustration 9: EMC-correct Electrical Installation
Installation
Operating Guide | VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570
20 | Danfoss A/S © 2019.12
