Control card, analogue inputs:
Number of analogue voltage inputs ............................................................................................................. 1 pcs.
Terminal number ................................................................................................................................................ 53
Voltage level ................................................................................................................. ± 0 - 10 V DC (scaleable)
Input resistance, R
i
........................................................................................................................ approx. 10 k 
Max. voltage .................................................................................................................................................. 20 V
Number of analogue current inputs ............................................................................................................. 1 pcs.
Terminal number ................................................................................................................................................ 60
Current level .................................................................................................................... 0/4 - 20 mA (scaleable)
Input resistance, R
i
......................................................................................................................... approx. 300 
Max. current ................................................................................................................................................ 30 mA
Resolution for analogue inputs ..................................................................................................................... 10 bit
Accuracy of analogue inputs ...................................................................................... Max. error 1% of full scale
Scan interval ......................................................................................................................................... 13.3 msec
The analogue inputs are galvanically isolated from the supply voltage (PEL V) and other high-voltage terminals.
See section entitled Galvanic Isolation.
Control card, pulse inputs:
Number of programmable pulse inputs ............................................................................................................... 2
Terminal number .......................................................................................................................................... 29, 33
Max. frequency at terminal 29/33 ........................................................................................ 67.6 kHz (Push-pull)
Max. frequency at terminal 29/33 ..................................................................................... 5 kHz (open collector)
Min. frequency at terminal 33 ....................................................................................................................... 4 Hz
Min. frequency at terminal 29 ..................................................................................................................... 30 Hz
Voltage level ...................................................................................................... 0 - 24 V DC (PNP positive logic)
Voltage level, logic ’0’ ............................................................................................................................. < 5 VDC
Voltage level, logic ’1’ ........................................................................................................................... > 10 V DC
Maximum voltage on input ...................................................................................................................... 28 V DC
Input resistance, R
i
.......................................................................................................................... approx. 2 k 
Scan interval ......................................................................................................................................... 13.3 msec
Resolution ..................................................................................................................................................... 10 bit
Accuracy (100 Hz- 1 kHz) terminal 33 .................................................................. Max. error: 0.5% of full scale
Accuracy (1 kHz - 67.6 kHz) terminal 33 .............................................................. Max. error: 0.1% of full scale
The pulse input is galvanically isolated from the supply voltage (PEL V) and other high-voltage terminals. See
section entitled Galvanic Isolation.
Control card, digital/frequency output:
Number of programmable digital/pulse outputs ........................................................................................... 1 pcs.
Terminal number ................................................................................................................................................ 46
Voltage level at digital/frequency output .......................................................................... 0 - 24 V DC (O.C PNP)
Max. output current at digital/frequency output ......................................................................................... 25 mA.
Max. load at digital/frequency output ............................................................................................................ 1 k

Max. capacity at frequency output .............................................................................................................. 10 nF
Minimum output frequency at frequency output .......................................................................................... 16 Hz
Maximum output frequency at frequency output ....................................................................................... 10 kHz
Accuracy on frequency output .............................................................................. Max. error: 0.2 % of full scale
Resolution on frequency output ................................................................................................................... 10 bit
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals. See
section entitled Galvanic Isolation.
