VLT
®
FCM Series
Used together with Process, closed loop
mode (parameter 100).
Description of choice:
Is only active when parameter 203 has been
set to Min-Max [0].
415 Maximum feedback
(MAX. FEEDBACK)
Value:
(par. 414) FB
LOW
- 100,000,000
[- 100000000]
✭1.500.000
[1500000]
Function:
See description of parameter 414.
416 Reference/feedback unit
(REF/FEEDB. UNIT)
Value:
NO UNIT
[0]
✭%
[1]
PPM
[2]
RPM
[3]
bar
[4]
CYCLE/min
[5]
PULSE/s
[6]
UNITS/s
[7]
UNITS/min
[8]
UNITS/h
[9]
°C
[10]
Pa
[11]
l/s
[12]
m
3
/s
[13]
l/min
[14]
m
3
/min
[15]
l/h
[16]
m
3
/h
[17]
kg/s
[18]
kg/min
[19]
kg/h
[20]
t/min
[21]
t/h
[22]
m
[23]
Nm
[24]
m/s
[25]
m/min
[26]
°F
[27]
in wg
[28]
gal/s
[29]
ft
3
/s
[30]
gal/min
[31]
ft
3
/min
[32]
gal/h
[33]
ft
3
/h
[34]
lb/s
[35]
lb/min
[36]
lb/h
[37]
lb ft
[38]
ft/s
[39]
ft/min
[40]
Function:
Choose among different units to be shown
on the display.
This unit is also used directly in Process regula t ion,
closed loop as a unit for Minimum/Maximum reference
(parameters 204/205) and Minimum/ Maximum
feedback (parameters 414/415).
The possibility of choosing a unit in parameter
416 will depend on the choices made in the
following parameters:
Par. 002 Local/remote control.
Par. 013 Local control/config. as par. 100.
Par. 100 Configuration.
S
elect parameter 002 as Remote control
If parameter 100 is selected as Speed regulation,
open loop, the unit selected in parameter 416
can be used in displays (par. 009-12 Feedback
[unit]) of process parameters.
Note: The reference can only be shown in Hz
(Speed regulation, open loop).
If parameter 100 is selected as Process regulation,
closed loop, the unit selected in parameter 416
will be used when displaying both reference
(par. 009- 12: Reference [unit]) and feedback
(par. 009-12: Feedback [unit]).
S
elect parameter 002 as Local control
If parameter 013 is chosen as LCP control and
open loop or LCP digital control and open loop ,
the reference will be given in Hz, regardless of the
choice made in parameter 416. If parameter 013 is
chosen as LCP control/as par. 100 or LCP digital
control/as par. 100, the unit will be as described
above under parameter 002, Remote-control.
NB!:
The above applies to display of Reference
[unit] and Feedback [unit].IfReference [%] or
Feedback [%] is selected, the value displayed
will be in the form of a percentage of the selected range.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
