Danfoss VLT HVAC Basic Drive FC 101 User Manual

Relays and terminals on H7 enclosure
1
2
3
4
130BB763.10
1 Line power
2 Relays
3 Ground
4 Motor
Figure 3.5 H7 Enclosure
IP20, 380-480 V, 55-75 kW (70-100 HP)
IP20, 200-240 V, 22-30 kW (30-40 HP)
IP20, 525-600 V, 45-55 kW (60-70 HP)
Relays and terminals on H8 enclosure
130BB764.10
1
2
3
4
98
97
96
99
95
93
92
91
L1
L1
L1
U
V
w
1 Line power
2 Relays
3 Ground
4 Motor
Figure 3.6 H8 Enclosure
IP20, 380-480 V, 90 kW (125 HP)
IP20, 200-240 V, 37-45 kW (50-60 HP)
IP20, 525-600 V, 75-90 kW (100-125 HP)
Installation VLT®HVAC Basic Drive FC 101
12 Danfoss A/S © 08/2014 All rights reserved. MG18A622
