Parameter Option Default Usage
1-10 Motor Construction
*[0] Asynchron
[1] PM, non-salient SPM
[2] PM, salient IPM, non
Sat.
[3] PM, salient IPM, Sat.
[0] Asynchron Setting the parameter value might
change these parameters:
1-01 Motor Control Principle
1-03 Torque Characteristics
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
1-17 Voltage filter time const.
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-30 Stator Resistance (Rs)
1-33 Stator Leakage Reactance (X1)
1-35 Main Reactance (Xh)
1-37 d-axis Inductance (Ld)
1-38 q-axis Inductance (Lq)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-44 d-axis Inductance Sat. (LdSat)
1-45 q-axis Inductance Sat. (LqSat)
1-46 Position Detection Gain
1-48 Current at Min Inductance for
d-axis
1-49 Current at Min Inductance for
q-axis
1-66 Min. Current at Low Speed
1-70 PM Start Mode
1-72 Start Function
1-73 Flying Start
4-14 Motor Speed High Limit [Hz]
4-19 Max Output Frequency
4-58 Missing Motor Phase Function
14-65 Speed Derate Dead Time
Compensation
1-20 Motor Power
0.12–110 kW/0.16–150
HP
Size related Enter the motor power from the
nameplate data.
1-22 Motor Voltage
50.0–1000.0 V Size related Enter the motor voltage from the
nameplate data.
1-23 Motor Frequency
20.0–400.0 Hz Size related Enter the motor frequency from
the nameplate data.
1-24 Motor Current
0.01–10000.00 A Size related Enter the motor current from the
nameplate data.
1-25 Motor Nominal Speed
50.0–9999.0 RPM Size related Enter the motor nominal speed
from the nameplate data.
Programming VLT®HVAC Basic Drive FC 101
30 Danfoss A/S © 08/2014 All rights reserved. MG18A622
