Parameter Overview
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[160] No alarm
[161] Running reverse
[165] Local ref. active
[166] Remote ref. active
[167] Start command activ
[168] Drive in hand mode
[169] Drive in auto mode
[193] Sleep Mode
[194] Broken Belt Function
[196] Fire Mode
[198] Drive Bypass
5-41 On Delay, Relay
0.00 - 600.00 s, *0.01 s
5-42 Off Delay, Relay
0.00 - 600.00 s, *0.01 s
5-5* Pulse Input
5-9* Bus Controlled
5-90 Digital and Relay Bus
Control
0 - 0xFFFFFFFF, * 0
6-** Analog In/Out
6-0* Analog I/O Mode
6-00 Live Zero Timeout Time
1 - 99s, * 10
6-01 Live Zero Timeout Function
*[0] Off
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
6-1* Analog Input 53
6-10 Terminal 53 Low Voltage
0.00 - 10.00 V, * 0.07
6-11 Terminal 53 High Voltage
0.00 - 10.00 V, * 10.00
6-12 Terminal 53 Low Current
0.00 - 20.00, * 4.00 mA
6-13 Terminal 53 High Current
0.00 - 20.00, * 20.00 mA
6-14 Terminal 53 Low Ref./Feedb.
Value
-4999.000 - 4999.000, * 0.000
6-15 Terminal 53 High Ref./
Feedb. Value
-4999.000 - 4999.000, * 50.000
6-16 Terminal 53 Filter Time
Constant
0.01 - 10.00 s, * 0.01
6-19 Terminal 53 mode
[0] Current mode
*[1] Voltage mode
6-2* Analog Input 54
6-20 Terminal 54 Low Voltage
0.00 - 10.00V, * 0.07
6-21 Terminal 54 High Voltage
0.00 - 10.00V, * 10.00
6-22 Terminal 54 Low Current
0.00 - 20.00, * 4.00mA
6-23 Terminal 54 High Current
0.00 - 20.00, * 20.00mA
6-24 Terminal 54 Low Ref./Feedb.
Value
-4999.000 - 4999.000, * 0.000
6-25 Terminal 54 High Ref./
Feedb. Value
-4999.000 - 4999.000, * 50.000
6-26 Terminal 54 Filter Time
Constant
0.01 - 10.00, * 0.01
6-29 Terminal 54 mode [0]
Current mode
[0] Current mode
*[1] Voltage mode
6-7* Analog Output 45
6-70 Terminal 45 Mode
*[0] 0-20 mA
[1] 4-20 mA
[2] Digital Output
6-71 Terminal 45 Analog Output
*[0] No operation
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[106] Power
[139] Bus Control
6-72 Terminal 45 Digital Output
*[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready/remote control
[4] Standby / no warning
[5] Drive running
[6] Running / no warning
[7] Run in range/no warning
[8] Run on ref/no warning
[9] Alarm
[10] Alarm or warning
[12] Out of current range
[13] Below current, low
[14] Above current, high
[21] Thermal warning
[22] Ready, no thermal warning
[23] Remote, ready, no thermal
warning
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[35] External Interlock
[45] Bus Control
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[160] No alarm
[161] Running reverse
[165] Local ref. active
[166] Remote ref. active
[167] Start command activ
[168] Drive in hand mode
[169] Drive in auto mode
[193] Sleep Mode
[194] Broken Belt Function
[196] Fire Mode
[198] Bypass Mode
6-73 Terminal 45 Output Min
Scale
0.00 - 200.00%, * 0.00
6-74 Terminal 45 Output Max
Scale
0.00 - 200.00%, * 100.00
6-76 Terminal 45 Output Bus
Control
0.00 - 100.00%, * 0.00
6-9* Analog Output 42
6-90 Terminal 42 Mode
*[0] 0-20 mA
[1] 4-20 mA
[2] Digital Output
6-91 Terminal 42 Analog Output
*[0] No operation
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[105] TorquereltoRated
[106] Power
[139] Bus Control
6-92 Terminal 42 Digital Output
*[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready/remote control
[4] Enable / no warning
[5] Drive running
[6] Running / no warning
[7] Run in range/no warning
[8] Run on ref/no warning
[9] Alarm
[10] Alarm or warning
[12] Out of current range
[13] Below current, low
[14] Above current, high
[21] Thermal warning
[22] Ready, no thermal warning
[23] Remote, ready, no thermal
warning
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[35] External Interlock
[45] Bus Control
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[160] No alarm
[161] Running reverse
[165] Local ref. active
[166] Remote ref. active
[167] Start command activ
[168] Drive in hand mode
[169] Drive in auto mode
[193] Sleep Mode
[194] Broken Belt Function
[196] Fire Mode
[198] Drive Bypass
6-93 Terminal 42 Output Min
Scale
0.00 - 200.00%, * 0.00
6-94 Terminal 42 Output Max
Scale
0.00 - 200.00%, * 100.00
6-96 Terminal 42 Output Bus
Control
0.00 - 100.00%, * 0.00
8-** Comm. and Options
8-0* Comm. General Settings
8-01 Control Site
