Parameter Overview
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A low
[33] Set digital out B low
[34] Set digital out C low
[35] Set digital out D low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[60] Reset Counter A
[61] Reset Counter B
[70] Start timer 3
[71] Start timer 4
[72] Start timer 5
[73] Start timer 6
[74] Start timer 7
[100] Reset Alarm
14-** Special Functions
14-0* Inverter Switching
14-01 Switching Frequency
[0] Ran3
[1] Ran5
[2] 2.0 kHz
[3] 3.0 kHz
[4] 4.0 kHz
[5] 5.0 kHz
[6] 6.0 kHz
[7] 8.0 kHz
[8] 10.0 kHz
[9] 12.0kHz
[10] 16.0kHz
14-03 Overmodulation
[0] Off
*[1] On
14-08 Damping Gain Factor
0 - 100-%, * 96
14-1* Mains on/off
14-12 Function at Mains
Imbalance
*[0] Trip
[1] Warning
[2] Disabled
[3] Derate
14-2* Reset Functions
14-20 Reset Mode
*[0] Manual reset
[1] Automatic reset x 1
[2] Automatic reset x 2
[3] Automatic reset x 3
[4] Automatic reset x 4
[5] Automatic reset x 5
[6] Automatic reset x 6
[7] Automatic reset x 7
[8] Automatic reset x 8
[9] Automatic reset x 9
[10] Automatic reset x 10
[11] Automatic reset x 15
[12] Automatic reset x 20
[13] Infinite auto reset
14-21 Automatic Restart Time
0 - 600s, * 10
14-22 Operation Mode
*[0] Normal operation
[2] Initialisation
14-27 Action At Inverter Fault
[0] Off
*[1] On
14-28 Production Settings
*[0] No action
[1] Service reset
[3] Software Reset
14-29 Service Code
0 - 0x7FFFFFFF, * 0
14-3* Current Limit Ctrl.
14-4* Energy Optimising
14-40 VT Level
40 - 90%, * 90%
14-41 AEO Minimum Magnetisation
40 - 75%, * 66
14-5* Environment
14-50 RFI Filter
[0] Off
*[1] On
14-51 DC-link Voltage Compen-
sation
[0] Off
*[1] On
14-52 Fan Control
*[0] Auto
[4] Auto Low temp env
14-53 Fan Monitor
[0] Disabled
*[1] Warning
[2] Trip
14-55 Output Filter
*[0] No Filter
[1] Sine-Wave Filter
[3] Sine-Wave Filter with Feedback
14-63 Min Switch Frequency
1 - 16kHz, * 1
15-** Drive Information
15-0* Operating Data
15-00 Operating Hours
0 - 2147483647, * 0
15-01 Running Hours
0 - 2147483647, * 0
15-02 kWh Counter
0 - 65535, * 0
15-03 Power Up's
0 - 2147483647, * 0
15-04 Over Temp's
0 - 65535, * 0
15-05 Over Volt's
0 - 65535, * 0
15-06 Reset kWh Counter
*[0] Do not reset
[1] Reset counter
15-07 Reset Running Hours
Counter
*[0] Do not reset
[1] Reset counter
15-3* Fault Log
15-30 Fault Log:
Error Code 0 - 255, * 0
15-4* Drive Identification
15-40 FC Type
15-41 Power Section
15-42 Voltage
15-43 Software Version
15-44 OrderedTypeCode
15-46 Frequency Converter
Ordering No
15-47 Power Card Ordering No
15-48 LCP Id No
15-49 Software ID Control Card
15-50 Software ID Power Card
15-51 Frequency Converter Serial
Number
15-53 Power Card Serial Number
16-** Data Readouts
16-0* General Status
16-00 Control Word
0 - 65535, * 0
16-01 Reference [Unit]
-4999.000 - 4999.000, * 0.000
16-02 Reference
% -200.0 - 200.0, * 0.0
16-03 Status Word
0 - 65535, * 0
16-05 Main Actual Value [%]
-200.00 - 200.00, * 0.00
16-09 Custom Readout
0.00 - 9999.00, * 0.00
16-1* Motor Status
16-10 Power [kW]
0.000-4.294, 967.500, *0.000
16-11 Power [hp]
0.000 - 2.294, 967.500 *0.000
16-3* Drive Status
16-30 DC Link Voltage
0 - 65535, * 0
16-34 Heatsink Temp.
0 - 255, * 0
16-35 Inverter Thermal
0 - 255%, * 0
16-36 Inv. Nom. Current
0.00 - 655.35, * 0.00
16-37 Inv. Max. Current
0.00 - 655.35
16-38 SL Controller State
0 - 255, * 0
16-5* Ref. and Feedb.
16-50 External Reference
-200.0 - 200.0%, * 0.0
16-52 Feedback
-4999.000 - 4999.000, * 0.000
16-6* Inputs and Outputs
16-60 Digital input
0 - 65535, * 0
16-61 Terminal 53 Setting
*[0] Current mode
[1] Voltage mode
16-62 Analog Input 53
0.00 - 10.00, * 1.00
16-63 Terminal 54 Setting
*[0] Current mode
[1] Voltage mode
16-64 Analog Input 54
0.00 - 20.00, * 1.00
16-65 Analog Output 42 [mA]
0.00 - 20.00, * 0.00
16-61 Digital Output
16-72 Counter A
-32768 - 32767, * 0
16-73 Counter B
-32768 - 32767, * 0
16-79 Analog output 45
20 - 20mA, * 0
16-8* Fieldbus / FC Port
16-86 FC Port REF 1
-32768 - 32767, * 0
16-9* Diagnosis Readouts
16-90 Alarm Word
0 - 0xFFFFFFFFUL, * 0
16-91 Alarm Word 2
0 - 0xFFFFFFFFUL, * 0
16-92 Warning Word
0 - 0x7FFFFFFFUL, * 0
16-93 Warning Word 2
0 - 0x7FFFFFFFUL, * 0
16-94 Ext. Status Word
0 - 0x7FFFFFFFUL, * 0
16-95 Ext. Status Word 2
0 - 0x7FFFFFFFUL, * 0
18-**Extended Motor Data
18-1* Firemode Log
18-10 Firemode log: Event
0-255, *0
20-** FC Closed Loop
20-0* Feedback
20-00 Feedback 1 Source
*[0] No function
[1] Analog in 53
[2] Analog in 54
[100] Bus Feedback 1
