Danfoss VLT PROFIBUS DP MCA 101 Installation Guide

1 Introduction
1.1 Purpose of the Manual
This installation guide provides information for quick instal-
lation of a VLT
®
PROFIBUS DP MCA 101 in the VLT
®
frequency converter.
The installation guide is intended for use by qualied
personnel. Users are assumed to know the VLT
®
frequency
converter, with PROFIBUS technology, and with the PC or
PLC used as a master in the system.
Read the instructions before installation and ensure that
instructions for safe installation are observed.
VLT
®
is a registered trademark.
1.2 Additional Resources
Resources available for the frequency converters and
optional equipment:
•
The VLT
®
Operating Instructions provide the
necessary information for getting the frequency
converter up and running.
•
The VLT
®
Design Guide provides detailed
information about capabilities and functionality
to design motor control systems.
•
The VLT
®
Programming Guide provides greater
detail on working with parameters and many
application examples.
•
The VLT
®
PROFIBUS DP MCA 101 Installation Guide
provides information about installing the
PROFIBUS and troubleshooting.
•
The VLT
®
PROFIBUS DP MCA 101 Programming
Guide provides information about conguring the
system, controlling the frequency converter,
parameter access, programming, troubleshooting,
and some typical application examples.
Supplementary publications and manuals are available
from Danfoss. See vlt-drives.danfoss.com/Support/Technical-
Documentation/ for listings.
1.3
Product Overview
1.3.1 Intended Use
This installation guide relates to PROFIBUS interface
ordering numbers 130B1100 and 130B1200.
The PROFIBUS interface enables communication between a
VLT
®
frequency converter and any master complying with
the PROFIBUS standard. Communication can be congured
via MCT 10 Set-up Software. The PROFIBUS interface
supports PROFIBUS DP-V1.
VLT
®
PROFIBUS DP MCA 101 is intended for use with:
•
VLT
®
HVAC Drive FC 102.
•
VLT
®
Refrigeration Drive FC 103.
•
VLT
®
AQUA Drive FC 202.
•
VLT
®
AutomationDrive FC 301/FC 302.
•
VLT
®
DriveMotor FCP 106.
•
VLT
®
DriveMotor FCM 106.
Requirements to the master:
A PLC or PC that:
•
Has a serial communication card with PROFIBUS
master class 1 capability.
•
Supports all PROFIBUS communication services
required by the application.
•
Fulls requirements of the PROFIBUS standard.
•
Fulls requirements of the PROFIBUS frequency
converter prole and its company-specic
implementation, PROFIdrive.
•
Fulls requirements of the relevant VLT
®
frequency converter.
1.3.2 Items Supplied
When the eldbus option is not factory-mounted, the
following items are supplied:
•
Fieldbus option and connector.
•
LCP cradle.
•
Front covers (in various sizes).
•
Stickers.
•
Accessories bag (including EMC bracket).
•
Installation Guide.
1.4
Approvals and Certications
More approvals and certications are available. For more
information, contact a local Danfoss partner.
Introduction
VLT
®
PROFIBUS DP MCA 101
2 Danfoss A/S © 07/2015 All rights reserved. MG33C602
11
