SPECIFICATIONS
INPUT 1 TO SELECTED LINE OUT AND SPEAKERS
Frequency Response +0, -0.5dB from <10 Hz to >80 kHz
THD+N < 0.0025% @+4dBu
IMD (SMPTE) < 0.0025% @ +4dBu
Crosstalk rejection >108dB
Noise < -93 dB, unweighted
NOTE: Speaker outs can run at -6dB (factory setting) or unity gain (remove jumpers 3 and 4)
Maximum input level > +26 dBu
INPUT 2 TO SELECTED LINE OUT AND SPEAKERS
Frequency Response +0, -0.5dB from <10 Hz to >80 kHz
THD+N < 0.0025% @ +4dBu
IMD (SMPTE) < 0.0026% @ +4dBu
Crosstalk rejection > -98dB
Noise < -90 dB, unweighted
NOTE: Input 2 can run at -10dBV or -16dBV (by setting JP1 and JP2. Remove for -10dBV)
Default factory setting is -16dBV to accommodate 1/8” headphone outputs of iPhones and cell phones
Frequency response +0, -0.5dB from <10Hz to >50kHz
OUTPUTS
The meter and speakers outputs are fully balanced and 600 ohm drive capable to >+26dBu.
Volume knobs track better than +- 0.5dB from unity to -40dB.
The headphone amp can easily drive several sets of cans.
Maximum output level > +26 dBu
Shipping weight (in carton) 7 lbs
Dimensions 12 3/4” wide X 8” deep X 1 5/8” high
