Balancing Modes
DYN
- The dynamic balance
mode clamps balance
correction weights on the two
outside edges of the steel
wheel.
ALUS -
the ALUS balance
mode is a custom mode and
utilizes adhesive balance
correction weights on inner and
center plane locations
chosen
by the operator
.
ALU 1
- The ALU 1 balance
mode utilizes adhesive balance
correction weights on the inner
plane behind the wheel spokes
and on the outer plane.
ALU 2 -
The ALU 2 balance
mode clamps balance
correction weights on the inner
edge and utilizes adhesive
correction weights to the center
plane of the wheel.
ALU 3
– The ALU 3 balance
mode clamps balance
correction weights on the inner
edge and utilizes adhesive
weights on the center plane.
ALU 4 -
The ALU 4 balance
mode clamps balance
correction weights on the inner
edge and utilizes adhesive
weights on the outer plane
outside the spoke.
