Dantherm 4000 User Manual

Spare parts, continued
Illustration to be added at a later date.
Fig. 13
This list shows available spare parts for the evaporator section of the unit.
Pos. Number Description
1 087280 CC0 Assembly with Housing and Overlay, DC4000 & DC6000
2 707746 Fan, 48VDC, DC4000 & DC6000
3 087281 Compressor DC Drive Control Board, DC4000 & DC6000
4 081942 Coil, Evaporator, DC4000 & DC6000
5 707739 Heater Element, 500W, DC4000 & DC6000
298681 Thermostat, temp limiting, manual reset, open 170F, DC4000 &
DC6000
707605 Thermostat, Automatic Reset, 140F, DC4000 & DC6000
086941 Inrush Filter Control Board, DC4000 & DC6000
218010 Capacitor, Compressor, DC6000
707778 Relay, Heater, DC4000 & DC6000
707634 Plug, Terminal Block, CC0 External Connections, DC4000 & DC6000
Illustration, internal
parts
Sparepart list
Internal
1
2
4
3
5
DC4000/6000 OIM 12_2015
21
en
