34
EN
1. Use at screwdriver
to remove terminal
rail blocks.
2. Slide additional
terminal rail blocks
into place in this
order.
3. The terminal rail
block can also be
clipped on.
4. Place bridge in the
three blue terminal
rail blocks.
5. Press bridge rmly
into place.
6. Glass fuse in large
terminal rail block.
10A 5x20mm
6. Activate heater
as described in
operation chapter,
section "Code ºC"
Electrical heating coil for CDP dehumidier
Terminal Rail Assembly Procedure
