Dantherm HCH 5 Installation And Service Manual

1
060804 • Version 1.6 • 22.01.2019
en
Introduction
Overview
Introduction
This is the installation and service guide for the home ventilation units
HCH 5 and HCH 8 from Dantherm. The table of contents below lists the sections in this
guide.
Serial number
For any future inquiries regarding e.g. spare parts we kindly ask you to make a note of
the serial numbers of the units here: ______________________
This guide covers units with serial numbers higher than: 1708101457460
Warning
The ducting system must not be mounted until the unit is ready to operate. The power
must not be connected until the ducting system has been mounted.
The ventilation unit should not be used to dry newly built houses during construction or
immediately after construction.
The ducts must be dimmed and the units must not be connected until the house is
ready for occupation, which means that the house is clean and dry. This is to
prevent
any construction dust and condensed water from depositing in the ducting system and
to prevent any sanitation inconveniences from the ventilation units later on.
If above mentioned warnings are disrespected,
the warranty of the unit will be annulled
and any kind of maintenance will be done at the customers own expense.
Table of contents
This guide covers the following sections
Introduction
.................................................................................................................. 1
General information ............................................................................................... 2
Product description ................................................................................................ 4
Fittings and installations ........................................................................................ 6
How to balance the unit ....................................................................................... 12
Set points and control strategies .......................................................................... 16
Preventive maintenance ........................................................................................ 18
List of spare parts, HCH 5 and HCH 8 .................................................................. 22
Fault finding instruction ....................................................................................... 24
Technical data ...................................................................................................... 28
Dimensions .......................................................................................................... 30
Wiring diagram..................................................................................................... 31
Index ................................................................................................................... 32
