Technical data
Performance data
The table shows the technical performance data for HCH 5 and HCH 8.
Specification
Unit
HCH 5
HCH 8
Max. air flow at 100 Pa ext. pressure
(m
3
/h)
375
530
Heat exchanger
Dantherm Alu. Counterflow Heat Exchanger
Temperature efficiency
%
Up to 95
1
Filter class supply air/exhaust,
standard
ISO Coarse 75% (G4)/
ISO Coarse 75% (G4)
Operational temperature range with-
out pre-heat
°C
÷13
2
to + 50
Operational temperature range with
pre-heat
°C
÷ 30 to + 50
Cabinet data
The table shows the technical cabinet data for HCH 5 and HCH 8.
Specification
Unit
HCH 5
HCH 8
Height
mm
600
600
Width
mm
1180
1180
Depth (Standard mounting rail/rail
for plan mounting)
mm
580
780
Duct connection
mm
160
250
Weight, unit
kg
52
70
Weight including packaging
kg
66
84
Dimensions including packaging
(HxWxD)
mm
H: 740
W: 1200
D: 800
H: 738
W: 1200
D: 800
Outer cabinet material
Aluzink
Colour
RAL
Aluzink, grey
Cabinet insulation, styrene
mm
40
Insulation factor, cabinet
W/m
2
x °K
0,78
Fire classification, polystyrene cabi-
net
DIN 4102 class B1
Fire class, the whole unit
EN 13501 class E
Protection class
IP
20
Continued overleaf
1
Condensing operation.
2
Dantherm recommends preheating at temperatures under -6° C to ensure a balanced
operation.
