Step 3: Connect Gas Supply Pipe
(Gas Dryer Only)
For further assistance, refer to section on Gas
Requirements.
1. Make certain your dryer is equipped for use with
the type of gas in your laundry room.
2. Remove the shipping cap from the gas
connection at the rear of the dryer.
3. Connect to gas supply pipe.
4. Tighten all connections securely.
5. For L.P. (Liquefied Petroleum) gas connection,
refer to section on Gas Requirements.
Figure 3
D233I
1 New Stainless Steel Flexible Connector –
Use only if allowed by local codes
(Use Design CSA Certified Connector)
4 Black Iron Pipe
Shorter than 6.1 m (20 ft.) – Use 9.5 mm
(3/8 in.) pipe
2 1/8 in. NPT Pipe Plug
(For checking inlet gas pressure)
Longer than 6.1 m (20 ft.) – Use 12.7 mm
(1/2 in.) pipe
3 Equipment Shut-Off Valve – Installed within
1.8 m (6 ft.) of dryer
5 3/8 in. NPT Gas Connection
D233I
1
2
3
4
5
