26
COMMUNICATOR CODES
Each of the following communication codes contain four (4) locations referred to as Data 1, Data 2, Data 3 and Data 4. The
first three locations are used for either enabling or disabling and or determining the reporting channel or event number for
the selected communication code. Data 4 is used to determine which phone number(s) is used when Dual or Split reporting
is enabled and or whether that communication event is recorded into the internal event log. Refer to the Data 1, 2, 3, and
4 listing below for more detail. Only Ademco High Speed and Contact I.D. are covered in this manual, for detail on
other formats please refer to the nearest sales branch.
DATA 1 - When Contact I.D is enabled, Data 1 is used to enable and or select the communicator code for the selected
communicator event. Program in Data 1 the required digit from appendix 1 (options 1 thru 15) to select the required Contact
I.D event report code. Not all communicator codes are programmable in this manner, and only require a “1" in Data 1 to
enable the communicator event report. Refer to the individual communicator code location for further detail. When
Ademco High Speed is programmed, Data 1 is used to enable the communicator code for that event. Program a “1" to
enable the communicator event and a “0" to disable the communicator event. This process is valid for all the communicator
event other than Zones 1 thru 16 communicator event which are automatically enabled. The event report code is predefined
when Ademco High Speed is selected and can only be enabled or disabled. However, Zones 1 thru 16 can have their
Channel numbers changed in Data 3. Refer to the individual communicator code location for further detail.
DATA 2 - When Contact I.D is enabled, Data 2 is used to program the 10's digit of the point number. When Ademco High
Speed is programmed, Data 2 is not used.
DATA 3 - When Contact I.D is enabled, Data 3 is used to program the 1's digit of the point number. When Ademco High
Speed is programmed, Data 2 is used to program the channel number for Zones 1 thru 16. Note: only channel numbers
1 thru 8 are valid for Ademco High speed.
DATA 4 - Is used to select phone number (1 = “1"), phone number (2 = “2") , and the (internal log = “4") or any combination
of the three (3). When Dual or Split reporting is enabled in location 146 then the telephone number programmed in Data
4 for the selected communicator event is used to report that event. If Dual or Split reporting is not enabled then program
Data 4 to follow telephone number 1 for normal communicator event reporting. I.E. Report via telephone number 1 and if
unsuccessful try telephone number 2. If no Telephone is selected for a given communicator event that communicator
event will not be reported. If (internal log = “4") is enabled then each time that communicator event is reported it is also
recorded into the internal event log for future reference via a LCD Code pad in the smart buss mode or via the download
software. Note: The event log can only record communicator events when those communicator event s are enabled to
report. If the event log is required without communicator event reporting, enable the internal log by programming a “4" in
Data 4, and enable the communicator event in Data 1.
LOCATION 256-259: PROGRAMMING THE COMMUNICATOR CODE FOR ZONE 1
Locations 256-259 are used to control the communicator code for zone 1. Zone 1 is automatically enabled and when
contact I.D is selected the default report is event "130 - Burglary" with point “01" when in alarm. Refer to appendix 1 if a
different event type is required. When using Ademco High Speed, Zone 1 is defaulted to report, a "1555 5555 7" when in
alarm. Ademco High Speed is a predefined format and only the Channel number can be programmed in Data 3. The
defaults are “3:0:1:5" with telephone number 1 and the event log enabled.
LOCATION 260-263: PROGRAMMING THE COMMUNICATOR CODE FOR ZONE 2
Locations 260-263 are used to control the communicator code for zone 2. Zone 2 is automatically enabled and when
contact I.D is selected the default report is event "130 - Burglary" with point “02" when in alarm. Refer to appendix 1 if a
different event type is required. When using Ademco High Speed, Zone 2 is defaulted to report, a "5155 5555 7" when in
alarm. Ademco High Speed is a predefined format and only the Channel number can be programmed in Data 3. The
defaults are “3:0:2:5" with telephone number 1 and the event log enabled.
LOCATION 264-267: PROGRAMMING THE COMMUNICATOR CODE FOR ZONE 3
Locations 264-267 are used to control the communicator code for zone 3. Zone 3 is automatically enabled and when
contact I.D is selected the default report is event "130 - Burglary" with point “03" when in alarm. Refer to appendix 1 if a
different event type is required. When using Ademco High Speed, Zone 3 is defaulted to report, a "5515 5555 7" when in
alarm. Ademco High Speed is a predefined format and only the Channel number can be programmed in Data 3. The
defaults are “3:0:3:5" with telephone number 1 and the event log enabled.
LOCATION 268-271: PROGRAMMING THE COMMUNICATOR CODE FOR ZONE 4
