APPENDIX 2
This document describes the DL-250 reporting event codes when using the SIA format (format 14). The following codes are
programmable and are sent when the 100's digit is programmed as the event code. The 10's and 1's digit are then sent as a
zone identifier.
PROGRAMMED 100's DIGIT SIA CODE DEFINITION
0 PA PANIC ALARM
1 FA FIRE ALARM
2 PA PANIC ALARM
3 BA BURGLARY ALARM
4 GA GAS ALARM
5 KA HEAT ALARM
6 WA WATER ALARM
7 QA EMERGENCY ALARM
8 SA SPRINKLER ALARM
9 UA UNTYPED ALARM
10 HA HOLDUP ALARM
11 MA MEDICAL ALARM
12 ZA FREEZE ALARM
13 TA TAMPER ALARM
14 RP PERIODIC TEST
15 RESERVED
!!! IMPORTANT !!!
The following event codes are fixed but must be enabled by programming a 1 in the corresponding location.
REPORTING EVENT SIA CODE PROGRAMMING LOCATION
TAMPER TA 304
AUTOTEST RP 308
FAIL TO COMMUNICATE RT 312
AC LOSS AT 320
LOW BATTERY YT 324
AC RESTORE AR 328
BATTERY RESTORE YR 329
RESTORE CODE *R 332
BYPASS CODE *B 334
BYPASS RESTORE *U 334 / 332
TROUBLE CODE *T 336
TROUBLE RESTORE *R 336 / 332
OPENING OP 340
CLOSING CL 341
CANCEL OC 343
EARLY OPENING OK 344
FAIL TO CLOSE CI 348
DOWNLOAD COMPLETE RS 352
* The character transmitted in this location will be the first character in the SIA code from the top list for the event being
transmitted. If a "1" is programmed in location 332, and a Burglary Alarm (B A) restores, a B R will be transmitted. If a "1" is
programmed in location 336, and a Fire Alarm (F A) zone goes into Trouble, an (F T) will be transmitted.
