MTPL, international substitution characters

dec

35 36 64 91 92 93 94 96 123 124 125 126

hex

23 24 40 5B 5C 5D 5E 60 7B 7C 7D 7E

US ASCII

UK ASCII

Swedish

German

Portuguese

French

Italian

Spanish

Norwegian
