2. INSTALLATION
Package Contents
Fat Tester
Draft Shield
Pan Support
Power Cable
In-Use Cover
Sample Test Kit (10 Test)
Instruction Manual
Selecting the Location
Operate the Fat tester on a firm, level surface.
Select a location that is safe and with adequate ventilation. Fire, corrosive or toxic fumes and other hazards associated with the test
samples will require specially prepared locations.
Ensure that the location has easy access to the local AC power supply.
Avoid locations with rapid temperature changes, excessive humidity, air currents, vibrations, electromagnetic fields, heat or direct
sunlight.
Installing Components
(1) Install and position Draft Shield
(2) Install Pan Support, turn until it engages
into position
(Optional Sample Pan Handler Not Included)
- Slide an empty sample pan under the pan
handler, then place over the pan support.
Verify that the input voltage printed on the voltage identification label information and the plug
type matches the locations AC power supply.
Connect the supplied power cable to the power input receptacle at the rear of the Fat tester
and into a properly grounded power outlet.
Power: On (short press) / Off / Standby Mode (long press)
When powered on from standby mode, the Fat tester is ready for immediate use.
See also Section 1, Safety Precautions.
After connecting the Fat tester to the AC supply (standby mode), allow the Fat tester to warm up for at least 15
minutes for best results.
